Product Description:

The VCP35.2ECN-003-SR-NN-PW is an operator terminal produced by Bosch Rexroth Indramat within the VCP IndraControl Terminals series. Deployed on machine fronts or control panels, it provides a touch-driven human-machine interface that relays commands and status data between shop-floor equipment and higher-level controllers. Its role in industrial automation is to combine visualization, parameter entry, and diagnostic functions in one compact unit while reducing wiring complexity and decentralizing user interaction.

The screen measures 26.4 cm (10.4 in), and this diagonal combines with a native 640 × 480 pixel matrix to present process graphics with moderate detail. Color depth reaches 256 colors on a TFT panel, so alarms and trend lines can be distinguished without grayscale dithering. Electrical demand stays low; the unit draws only 19.2 W, allowing it to share 24-volt power buses with sensors and I/O modules. A RISC ARM9 200 MHz processor handles screen refresh, protocol conversion, and script execution without the latency associated with external PCs. For application logic, recipes, and language tables, the terminal provides 3 MB of battery-backed SRAM, permitting rapid writes while retaining data through power cycles.

Complementing that volatile space is a nonvolatile store of 16 MB flash that secures firmware and boot images against unintentional loss. The aluminum bezel carries IP65 front protection, so jets of water or airborne dust do not reach the electronics when the panel is sealed into an enclosure, while the rear remains IP20 for cabinet ventilation. A regulated 24 V DC supply enters through a pluggable terminal block, which simplifies installation. Weighing only 2.3 kg, the device can be mounted on swing arms or lightweight doors without adding counterbalances while still supporting Ethernet TCP/IP, dual USB host ports, and an RS232/RS485 serial channel for controller connectivity.
