VCP08.2DTN-003-SR-NN-PW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911311498
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat VCP08.2DTN-003-SR-NN-PW is part of the VCP IndraControl Terminals series and features a 3.8 inch FSTN display with a resolution of 320 x 240. It comes equipped with a RISC ARM9 CPU, 16 MB of flash memory, and 3 MB of application memory. The device has front protection rated at IP65, a supply voltage of 24 VDC, and measures 205 x 155 x 55 mm.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The VCP08.2DTN-003-SR-NN-PW is an operator terminal developed by Bosch Rexroth Indramat within the VCP IndraControl Terminals series. This panel combines touch input and integrated processing so that machine states, setpoints, and alarms can be displayed at the interface and forwarded to the supervising PLC. In an automation cell, it serves as the user-accessible layer between motion drives, safety devices, and the control network, allowing parameter editing and status visualization from a sealed front plate.
A RISC ARM9 processor runs the runtime environment and manages data storage held in 3 MB of application memory for screen objects and scripts. Recipes and other retained project data are stored in a non-volatile 16 MB flash module, which preserves them during power loss. Logic, backlight, and communication circuits draw only 6 W, so cabinet heat generation stays low and passive ventilation is often sufficient. The terminal operates from a control supply of 24 VDC, allowing it to share a common bus with sensors and I/O modules without extra converters. These electronic components are mounted on multilayer boards attached to an aluminum carrier that helps move heat away from temperature-sensitive parts.
Operator feedback appears on a monochrome FSTN screen with a resolution of 320 × 240 pixels. Its compact 3.8 in diagonal gives clear character definition for lists and numeric fields without requiring a large panel cutout. The bezel and gasket combination provides a front sealing class of IP65, so washdown splashes or airborne oil mist cannot reach the circuitry, while the rear remains open to convection at IP20. With overall dimensions of 205 × 155 × 55 mm, the terminal fits standard 92 mm deep enclosures and still leaves space for wiring bends.
Frequently Asked Questions about VCP08.2DTN-003-SR-NN-PW:
Q: How much application memory is available on the VCP08.2DTN-003-SR-NN-PW terminal?
A: The VCP08.2DTN-003-SR-NN-PW offers an application memory of 3 MB for storing user programs and data.
Q: What type of CPU does the VCP08.2DTN-003-SR-NN-PW use?
A: This terminal is equipped with a RISC ARM9 CPU for its processing functions.
Q: What is the front protection rating of the VCP08.2DTN-003-SR-NN-PW terminal?
A: The front of the VCP08.2DTN-003-SR-NN-PW is protected with an IP65 rating, ensuring resistance to dust and water jets.
Q: What are the size and resolution of the VCP08.2DTN-003-SR-NN-PW display?
A: The display measures 3.8 inches and features a resolution of 320 x 240 pixels.
Q: What is the supply voltage and power consumption of the VCP08.2DTN-003-SR-NN-PW?
A: This device operates on a 24 VDC supply voltage and consumes 6 watts of power.
