Product Description:

The VCP05.2DSN-003-PB-NN-PW is a compact operator terminal produced by Bosch Rexroth Indramat for the VCP IndraControl Terminals series. It functions as a human-machine interface that lets plant personnel visualize status data and send commands to PLC-controlled equipment on the factory floor. By combining the display, processor, and communication access in one sealed unit, it supports local machine control where panel space is limited and front-panel protection is important. This layout makes the terminal suitable for equipment that needs direct status viewing and local input at the machine.

Processing is handled by a RISC ARM9 CPU clocked at 200 MHz, giving the terminal enough throughput for screen updates and communication tasks without an external computer. Program storage resides in a 16 MByte flash module, while runtime variables are buffered in 32 MByte of SDRAM to support larger visualization projects. An additional 3 MByte of application memory stores compiled control logic and recipe data separately from the main operating functions. This memory arrangement supports multilingual screens, alarms, and trend displays while keeping response times consistent during normal operation.

The integrated Ethernet port supports 10/100 Base-T communication, allowing the terminal to connect to standard automation networks with controllers and drives. Its front panel is rated IP65 when mounted with the proper gasket, which helps keep dust and low-pressure water jets away from the front of the unit. Internal electronics operate from a single 24 V DC supply, which simplifies panel wiring where that control voltage is already available; typical power consumption is 6 W, so the terminal adds only a modest heat load to the enclosure. Two rear USB host connectors allow connection of flash drives or service devices for data backup and software updates without opening the cabinet.
