VAM40.2-PB-NA-TA-TA-VB-MA-1608-NN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911170772
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat VAM40.2-PB-NA-TA-TA-VB-MA-1608-NN is part of the VAM Machine Operator Panels series. It features 16 digital inputs, 8 digital outputs, and a Profibus DP-Slave fieldbus interface. The panel has a degree of protection rated at IP54, offers 30 short-stroke function keys, and operates with a 24 V DC supply.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The VAM40.2-PB-NA-TA-TA-VB-MA-1608-NN operator panel is built by Bosch Rexroth Indramat within the VAM Machine Operator Panels series. Designed for machine consoles, the unit consolidates push-buttons, key switches, and emergency-stop circuitry so that programmable controllers receive direct operator commands. By combining a sealed faceplate with a steel rear housing, the panel serves as a dedicated interface in packaging lines, assembly cells, and other automated equipment, routing low-voltage signals to field devices while withstanding dust and splashing fluids common on factory floors. Its layout keeps routine control functions at the machine front, so common actions can be handled without a separate handheld station.
Its front surface carries a protection level of IP54, allowing installation on cabinets that are not fully climate-controlled. Control signals enter through 16 digital inputs and leave via 8 digital outputs, with each group using 24 V logic. Communication with higher-level control systems is provided by a 1 × Profibus DP-Slave port that supports cyclic data exchange. Operators issue commands through 30 short-stroke keys, while a four-position key switch selects operating modes. Two normally closed and one normally open emergency-stop contacts interrupt power when the red mushroom button is pressed, helping the panel relay a stop request to the connected safety circuit.
The panel measures 407 × 169 × 58 mm and fits a cabinet opening of 379 × 141 mm with a required mounting depth of 102 mm. Internal electronics draw up to 1.7 A from the I/O supply of 24 V DC, while the logic circuits require an additional 0.5 A at the same voltage. Overcurrent protection is provided by a replaceable 3 A fuse. The assembly uses Class 1 protection and a fuse-protected I/O design, and the stated current draw helps with power-source sizing inside the control cabinet. The shallow rear housing also supports recessed mounting where wiring space behind the front panel is limited.
Frequently Asked Questions about VAM40.2-PB-NA-TA-TA-VB-MA-1608-NN:
Q: How many digital inputs does the VAM40.2-PB-NA-TA-TA-VB-MA-1608-NN panel support?
A: This panel provides 16 digital inputs, allowing connection of multiple input devices.
Q: What is the degree of protection rating for the VAM40.2-PB-NA-TA-TA-VB-MA-1608-NN?
A: The VAM40.2-PB-NA-TA-TA-VB-MA-1608-NN offers an IP54 degree of protection, providing limited dust ingress and protection against splashing water.
Q: How many function keys are available on the VAM40.2-PB-NA-TA-TA-VB-MA-1608-NN panel?
A: This model features 30 short-stroke function keys for effective operator input.
Q: What is the I/O supply voltage for the VAM40.2-PB-NA-TA-TA-VB-MA-1608-NN?
A: The I/O supply for this panel is 24 V DC, enabling standard low-voltage operation.
Q: What type of fieldbus interface does the VAM40.2-PB-NA-TA-TA-VB-MA-1608-NN support?
A: The VAM40.2-PB-NA-TA-TA-VB-MA-1608-NN includes a Profibus DP-Slave fieldbus interface for system communication.
