The Bosch Rexroth Indramat TVM 1.2-050-W0 is a power supply module from the TVM Power Supply Modules series. It features a continuous output current of 25 Amps and uses natural convection for cooling. The module supports a main input voltage of AC 220 Volts, operates at 50-60 Hz, and weighs 14.83 kilograms.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The TVM 1.2-050-W0 power supply module is produced by Bosch Rexroth Indramat and belongs to the TVM Power Supply Modules series. As a regulated supply, it rectifies plant mains and maintains a stable DC link for compatible Indramat drive controllers. An internal bleeder dissipates regenerated energy returned from braking axes, so the shared bus can remain within its intended operating range during deceleration. The unit is built for multi-axis drive cabinets, and its series 1 construction with configuration code 2 suits industrial automation systems where several axes operate from a common power source.
The electrical interface is aligned with common European factory mains. It receives AC 220 V from a three-phase line at 50-60 Hz, which makes it suitable for standard industrial supply networks. After rectification and filtering, the module delivers a stabilized 300 VDC bus to connected servo inverters. For continuous motion tasks, it can supply 25 A of output current, while its 50 A type current indicates permissible short-term surge capacity. This arrangement supports shared DC-bus operation when several connected axes accelerate, run, and decelerate on the same supply module.
Thermal management relies on natural convection, so cabinet airflow around the housing should remain unobstructed and the mounting space should allow heat to rise away from the module. The built-in bleeder resistor continuously dissipates up to 0.30 kW of regenerative power to help prevent DC-link overvoltage during braking events. During start-up or line disturbances, the supply can momentarily tolerate a mains current of 20 A, which matches the stated peak input demand for the unit. The module has a mass of 14.83 kg, giving it a solid panel-mounted form without calling for additional bracing in typical drive cabinets.
Frequently Asked Questions about TVM 1.2-050-W0:
Q: What is the continuous output current for the TVM 1.2-050-W0 power supply module?
A: The TVM 1.2-050-W0 is capable of providing a continuous output current of 25 A.
Q: What is the DC link voltage of the Bosch Rexroth Indramat TVM 1.2-050-W0?
A: This module operates with a DC link voltage of 300 VDC.
Q: Does the TVM 1.2-050-W0 support 3-phase AC 220 V main input voltage?
A: Yes, the TVM 1.2-050-W0 requires a 3-phase AC 220 V main input for operation.
Q: How is the TVM 1.2-050-W0 power supply module cooled?
A: The TVM 1.2-050-W0 uses natural convection as its cooling method.
Q: What main input frequency does the TVM 1.2-050-W0 power supply module support?
A: The main input frequency supported by this module ranges from 50 to 60 Hz.
