The Bosch Rexroth Indramat RMA02.2-32-DC024-050 is part of the RECO Drive Modules series and features 32 FET transistor switch outputs arranged in four groups of eight. It provides a turn-on voltage of 24 V DC and supports a maximum output current of 0.5 Amps per output. The module's dimensions are 192 mm in height, 41.3 mm in width, and 81 mm in depth.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The RMA02.2-32-DC024-050 output module is supplied by Bosch Rexroth Indramat within the RECO Drive Modules series. Designed for rack-mounted installations, the board accepts logic signals from a central controller and switches them to actuators in an industrial cell. By converting control-level commands into field-level power, the module supports orderly sequencing of valves, lamps, and interlocks while maintaining electrical isolation between the control electronics and the devices being energized. This separation helps protect the control side from disturbances that can appear on load wiring during routine machine operation. Because it is intended for distributed machine signaling, the module separates low-power controller logic from the higher-current loads used for indication and actuation.
The module energizes each channel once the rail provides a turn-on threshold of 24 V DC. A total of 32 outputs are present, and every channel can deliver up to 0.5 A per output, so small relays or pilot solenoids can be driven directly. Switching elements are implemented with a FET transistor switch, which reduces wear associated with mechanical contacts and helps keep switching response consistent over repeated cycles. Solid-state switching also avoids contact bounce during pulsed control tasks. Protection against wiring faults is built in; the circuitry is rated as short-circuit proof, so a downstream short causes the affected channel to shut off rather than damage the rack or upstream supply. This behavior is useful in tightly wired cabinets where field devices and their conductors are installed close together.
An internal current limit supervises each stage, and the outputs are arranged in 4 blocks of 8 outputs, which keeps channel grouping easy to follow during installation. The enclosure measures 81 mm deep, 192 mm high, and 41.3 mm wide, so the card fits within a standard RECO sub-rack without interfering with adjacent modules. These dimensions leave room for labeled terminal strips and support airflow along the board edge. The narrow format also helps preserve rack space for neighboring control modules. The grouped layout helps keep external wiring organized when several output channels are used on the same machine section.
Frequently Asked Questions about RMA02.2-32-DC024-050:
Q: How many outputs are available on the RMA02.2-32-DC024-050 module?
A: The RMA02.2-32-DC024-050 offers a total of 32 outputs, arranged in four groups of eight.
Q: What is the maximum output current per output for the RMA02.2-32-DC024-050?
A: Each output on this module can handle a current of up to 0.5 A.
Q: What switching technology is used in the output circuits of the RMA02.2-32-DC024-050?
A: The RMA02.2-32-DC024-050 uses FET transistor switches for its output circuits.
Q: Does the RMA02.2-32-DC024-050 offer short-circuit protection?
A: This module is short-circuit proof, providing protection for the outputs.
Q: What is the required turn-on voltage for the RMA02.2-32-DC024-050 outputs?
A: The RMA02.2-32-DC024-050 operates with a turn-on voltage of 24 V DC.
