The Bosch Rexroth Indramat RMA02.2-16-DC024-200 is a drive module from the RECO Drive Modules series with 16 outputs arranged in two sets of 8, each using a FET transistor switch circuit and supporting 2 amps per output. This unit features two galvanically isolated blocks, operates with a turn-on voltage of 24 V DC, and has dimensions of 192 mm in height, 81 mm in depth, and 41.3 mm in width.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The RMA02.2-16-DC024-200 output module is manufactured by Bosch Rexroth Indramat as part of the RECO Drive Modules series. Mounted on the backplane of a RECO rack, this card provides powered switching points that let a PLC or motion controller actuate field devices directly. It is intended for industrial automation cells that use 24-volt control wiring and need dense, rail-mounted output capacity without adding external relays or separate driver boards. Its design integrates semiconductor switching, status feedback LEDs, and protective circuitry in one compact enclosure.
The module presents 16 outputs arranged as 2 × 8 banks, and this layout supports logical grouping of actuators across conveyors or tooling stations. Each channel can supply 2 A per output, allowing direct drive of pneumatic valve coils or beacon lamps without auxiliary contactors. Switching is handled by a FET transistor switch, so voltage drop and heat dissipation stay lower than with electromechanical relays. The outputs energize once the field supply reaches 24 V DC, matching common safety-extra-low-voltage supplies. Protection is built in, and the card is short-circuit proof, so a fault on one line trips only that channel without damaging the board. With a width of 41.3 mm, the card occupies a single slot and keeps rack space usage low.
Additional safety and noise immunity are provided by an internal current limit that constrains fault energy and by two galvanically isolated blocks, which help prevent ground loops when the outputs feed separate machine sections. Mechanical dimensions support dense cabinets; depth is 81 mm and front height is 192 mm, so the card clears standard enclosure doors while leaving room for cable ducts. The board depth also allows rear cable bends without stressing plug-in connectors.
Frequently Asked Questions about RMA02.2-16-DC024-200:
Q: How many outputs are available on the RMA02.2-16-DC024-200 module?
A: The RMA02.2-16-DC024-200 features 16 outputs arranged in two groups of eight for flexible connectivity.
Q: What is the maximum output current supported per channel on the RMA02.2-16-DC024-200?
A: Each output on this module can handle a current of 2 A.
Q: Does the RMA02.2-16-DC024-200 have internal current limiting?
A: This module is equipped with an internal current limit for each output channel.
Q: What type of output circuit does the RMA02.2-16-DC024-200 use?
A: The output circuits utilize a FET transistor switch, enabling reliable signal switching.
Q: Are the outputs on the RMA02.2-16-DC024-200 short-circuit proof?
A: Yes, this model features short-circuit proof outputs for added operational safety.
