PSI6100.352-L1

  • Rated 4.4 (22 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: 1070086425
  • Call for Expedited Shipping and Product Condition Options
The PSI6100.352-L1 Power Supply Unit is manufactured by Rexroth Indramat Bosch. This unit is a Medium Frequency Inverter Type of Power Supply Unit with a INTERBUS Type of Timer. The colling for this power supply unit is a(n) Air Blower and the mains voltage is 400-480V.

PSI6100.352-L1

  • Rated 4.4 (22 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: 1070086425
  • Call for Expedited Shipping and Product Condition Options
The PSI6100.352-L1 Power Supply Unit is manufactured by Rexroth Indramat Bosch. This unit is a Medium Frequency Inverter Type of Power Supply Unit with a INTERBUS Type of Timer. The colling for this power supply unit is a(n) Air Blower and the mains voltage is 400-480V.
Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

The PSI6100.352-L1 is an MF inverter that is manufactured by Bosch Rexroth Company. It is designed for PSG 3000 welding transformers connection. It is mainly used in resistance welding of metals in industrial environments. During operation ensure safe clearance of more than 30 meters from residential areas, 10 meters to communication systems, and a 10-meter cable length of mains feeder. The PSI6100.352-L1 features an integrated control functionality that enables medium frequency welding, welding control, I/O interfaces such as serial and parallel, and a Fieldbus interface for communication. The control and monitoring functions are installed separately.

This type comes with a BOS-5000 operator interface that enables quick programming, operation, and diagnostics of the MF inverter system. Some of the integrated features that enable the PSI6100.352-L1 to control welding transformers include a weld timer, I/O interfaces, retrofitting a quality module, and an optional Fieldbus module. This type features air cooling method, a rated voltage of 400 V to 480 V, and a rated current of 110 A. the most ideal welding transformers to connect to include PSG 3100.00 A, PSG 3075.10 A, and PSG 3050.00 A. it features a 1 kHz clock frequency, a wire range of 35mm2, and basic switchgear cabinet loss of 69 W.

The PSI6100.352-L1 weighs approximately 20 kg, has a 170 W cabinet loss at maximum power, and maximum cooling loss of 360 W. it can be mounted on a mounting plate or vertically in a cabinet with IP 54 protection class. The MF inverter has an IP 20 protection class and comes with a metal oxide Varistor for overvoltage protection. Ambient conditions include operating temperature of 55 degrees, a storage temperature of -25 to 70 degrees, and a maximum installation elevation of 2000 meters above sea level. This product is available from Wake Industrial with a one-year warranty period.

PSI6100.352-L1 Documents

  • PSI6100352L1
  • PSI6100 352 L1
  • psi6100.352-l1

PSI6100.352-L1 Technical Specifications

Cooling: Air Blower
Mains Voltage: 400-480V
Type of Power Supply Unit: Medium Frequency Inverter
Type of Timer: INTERBUS
