PPC-R22.1N-T-V1-V2-NN-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911311755
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat PPC-R22.1N-T-V1-V2-NN-FW is a control unit from the PPC Controllers series with a nominal supply of 24 VDC and a protection rating of IP20. It supports up to 40 drives and features a DeviceNet fieldbus slave interface. This unit has 32 MB of flash memory, an RJ-45 Ethernet port with a maximum baud rate of 100 MBaud, and weighs 1.3 kilograms.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The PPC-R22.1N-T-V1-V2-NN-FW is a control unit manufactured by Bosch Rexroth Indramat for the PPC Controllers series. It serves as the central processor in distributed motion systems and can coordinate up to 40 drives while fitting into a compact RECO housing that slides directly onto DIN rails. By combining DeviceNet, SERCOS, and Ethernet communication in one platform, the unit supports axis coordination, diagnostics, and program download functions inside industrial automation cells. Its compact format also helps preserve space in control cabinets where multiple automation components share the same rail.
A DeviceNet slave interface supports speeds up to 500 KBaud, and the Ethernet channel is rated for 100 MBaud for communication with higher-level controllers. Three backplane connectors provide 3 expansion slots for optional I/O or memory cards, and the onboard flash capacity of 32 MB stores motion programs and parameter files. Internal electronics draw a maximum of 1.2 A, so the unit places a modest demand on the cabinet supply. Two serial ports support local service access, and the RJ-45 Ethernet jack simplifies network cabling inside control enclosures. A dedicated fieldbus chip labeled DNS03 maintains cyclic data exchange, while the fixed TCP/IP socket 5001 is reserved for remote diagnostics.
The controller operates from a nominal bus of 24 VDC and tolerates input ripple up to 4 Vpp without disrupting real-time functions. Its SERCOS fiber channel reaches 16 MBaud for coordination of high-speed drives. The housing carries an IP20 rating, and the RECO format keeps the weight to 1.3 kg, which helps limit the load on light-gauge DIN rail segments. The unit is design Version 1, and the installed memory is fixed with no additional expansion. The power header and two serial connectors are placed on the front face to keep wiring clear of the right-side RJ-45 network port.
Frequently Asked Questions about PPC-R22.1N-T-V1-V2-NN-FW:
Q: What is the maximum number of drives supported by the PPC-R22.1N-T-V1-V2-NN-FW controller?
A: The PPC-R22.1N-T-V1-V2-NN-FW controller supports up to 40 drives, making it suitable for managing complex multi-axis systems.
Q: What kind of Ethernet connectivity does the PPC-R22.1N-T-V1-V2-NN-FW offer?
A: This unit features an RJ-45 Ethernet port with a maximum baud rate of 100 MBaud for high-speed network communications.
Q: How much flash memory is included in the PPC-R22.1N-T-V1-V2-NN-FW, and can it be expanded?
A: The controller is equipped with 32 MB of flash memory but does not support memory expansion.
Q: What is the required supply voltage for the PPC-R22.1N-T-V1-V2-NN-FW controller?
A: The PPC-R22.1N-T-V1-V2-NN-FW has a nominal supply voltage requirement of 24 VDC.
Q: What housing design and protection rating does the PPC-R22.1N-T-V1-V2-NN-FW have?
A: This model is built with a RECO unit housing design and a protection rating of IP20.
