PPC-R22.1N-T-V1-NN-NN-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: 1070170295
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat PPC-R22.1N-T-V1-NN-NN-FW is a control unit from the PPC Controllers series with a nominal voltage of 24 VDC and onboard Ethernet support. It features a 4-digit alphanumeric display, three expansion slots, and a DeviceNet Master fieldbus interface. The unit weighs 1.3 kilograms and is designed for TS 35x27x15 DIN rail mounting with an IP20 protection rating.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The PPC-R22.1N-T-V1-NN-NN-FW control unit from Bosch Rexroth Indramat is part of the PPC Controllers series. Designed as a programmable motion and logic platform, the module orchestrates servo drives, distributed I/O, and operator terminals throughout automated packaging, printing, and material-handling lines. By fitting directly onto a DIN rail, it delivers centralized axis coordination and machine sequence control without occupying a full rack enclosure.
The module operates from a nominal supply of 24 VDC and remains functional down to 20 VDC, drawing a steady 1.2 A during normal processing. SERCOS fiber ports on the front panel sustain data rates up to 16 MBaud, ensuring rapid cyclic exchange with drives. Local software and user programs reside on a 32 MB CompactFlash card, and the controller carries 3 expansion slots for additional I/O or communication cards. A 4-digit alphanumeric display presents status codes, while onboard Ethernet provides TCP/IP access for diagnostics. Wiring uses 1.5 mm² conductors, and the double-width RECO housing snaps onto a TS 35 × 27 × 15 DIN rail. Two serial ports allow connection of external devices, the memory expansion bay is not equipped, and the controller is released as Design Version 1.
During power-up, the electronics can draw a peak of 20 A, so the external supply must tolerate this brief surge. After stabilization, the enclosure complies with the IP20 protection level, allowing installation inside ventilated control cabinets. The integrated fieldbus port functions as a DeviceNet Master, providing deterministic scan cycles in parallel with the high-speed SERCOS network. Total mass is 1.3 kg, which keeps strain on the DIN rail low during installation. The controller’s fixed double slot width also preserves front access to terminals even when all neighboring modules are populated.
Frequently Asked Questions about PPC-R22.1N-T-V1-NN-NN-FW:
Q: Does the PPC-R22.1N-T-V1-NN-NN-FW controller have Ethernet support?
A: The PPC-R22.1N-T-V1-NN-NN-FW controller offers onboard Ethernet support for network connectivity.
Q: What type of display does the PPC-R22.1N-T-V1-NN-NN-FW controller use?
A: This controller uses a 4-digit alphanumeric display for status and settings visualization.
Q: How many expansion slots does the PPC-R22.1N-T-V1-NN-NN-FW controller provide?
A: Three expansion slots are available on this controller for system flexibility.
Q: What is the nominal voltage required to operate the PPC-R22.1N-T-V1-NN-NN-FW controller?
A: This model operates with a nominal supply voltage of 24 VDC.
Q: What fieldbus interface is supported by the PPC-R22.1N-T-V1-NN-NN-FW controller?
A: The controller supports the DeviceNet Master fieldbus interface for industrial connections.
