Product Description:

The PPC-R22.1N-T-Q1-V1-N1-FW belongs to the PPC Controllers series produced by Bosch Rexroth Indramat. As a compact control unit, it supervises coordinated drive functions and cell-level logic, providing a centralized command layer for multi-axis motion in industrial automation lines. By combining drive orchestration with fieldbus data exchange, the controller bridges higher-level PLCs and individual servo drives, allowing deterministic motion sequences to be loaded and executed from onboard program memory.

This RECO-format housing contains 32 MB of flash memory that stores motion programs and parameter sets needed for startup without external media. The nominal input of 24 VDC supports the internal CPU, I/O circuitry, and option slots, while a brownout margin down to 19.2 VDC keeps logic alive during brief supply dips. For synchronous data traffic between multiple Rexroth controllers and drives, the unit offers the Cross Communication, DAQ03 interface, enabling cyclic exchanges in the sub-millisecond range. The enclosure follows the RECO unit mechanical style, making it slide directly into DIN rail racks that share a common backplane power bus. Hardware expansion is not installed, so an internal CompactFlash bay is omitted, conserving space and airflow inside the fanless chassis.

Up to 40 drive axes can be registered to the task scheduler, allowing large gantries, transfer lines, or printing towers to run from a single CPU image. System wiring remains tool-free because the card edge is recessed behind an IP20 cover, which prevents accidental contact and vents heat through the top slot apertures. Application-specific sequencing is added through the Option Card PLS module, NSW01; this mezzanine supplies phase-synchronous latch outputs for high-speed camming. The controller is Version 1, matching early PPC motion libraries for this hardware revision.
