Product Description:

The PPC-R22.1N-T-Q1-P1-P2-FW is a control unit produced by Bosch Rexroth Indramat for the PPC Controllers series. As a programmable platform, it coordinates motion sequences and data exchange between drives, I/O modules, and supervisory PLCs in industrial automation cells. Its purpose is to execute axis control algorithms while forwarding status information to higher-level networks. In production equipment, it can serve as the central logic layer between motion hardware and factory communication so coordinated axes can respond quickly to changing process conditions.

This controller is powered from a nominal bus of 24 VDC and draws up to 1.2 A during peak processing periods. Its embedded Ethernet channel reaches 100 MBaud, and the asynchronous serial interface can be set as high as 115200 Baud for command and status exchange. Socket access for remote diagnostics is available on TCP/IP port 5001, while two serial ports share the same board and support Cross Communication through the DAQ03 module. Profibus connectivity is provided by the DPS01 slave interface, and the optical rings accept two fiber pairs for redundant loop arrangements. This combination lets the unit exchange field data with surrounding devices while still handling local motion-related communication on the same platform. The RECO housing design also allows tool-free insertion into rail assemblies.

The enclosure carries an IP20 rating, so the controller is intended for installation inside a closed cabinet. The 24-volt supply should remain within a maximum ripple of 4 Vpp to support stable operation. The unit does not include internal memory expansion, so application code remains on the base flash. Because expansion memory is not provided, the application footprint must fit within the controller's built-in storage. With a mass of 1.3 kg, the module adds little load to the mounting rail. The controller is identified as Design Version 1.
