PPC-R22.1N-T-NN-P1-NN-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: 1070170294
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat PPC-R22.1N-T-NN-P1-NN-FW is a control unit from the PPC Controllers series, featuring a control supply of 24 VDC and a maximum I/O supply current of 2.6 Amps. It offers a 4-digit alphanumeric display, three digital inputs, two digital outputs, and includes both Profibus master and 10/100 MBaud Ethernet interfaces. This unit has 32 MB of flash memory, three expansion slots, and a weight of 1.3 kilograms, all housed in a RECO unit design with IP20 protection.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The PPC-R22.1N-T-NN-P1-NN-FW control unit is produced by Bosch Rexroth Indramat within the PPC Controllers series. This module functions as the central logic and motion coordinator in distributed industrial automation, linking drives, field devices, and higher-level networks from a compact RECO housing. By combining program execution, fieldbus management, and local I/O handling, it streamlines machine sequencing and axis synchronization. It can supervise machine logic and motion-related communication at the same time, which helps reduce the need for separate control hardware in the rack.
The controller is powered from a control supply of 24 VDC and draws a steady 1.2 A from that rail, while the separate I/O channel can deliver up to 2.6 A for sensors and actuators. Version 1 electronics are mounted on a double-width card that inserts into the RECO rack. Processing resources include 32 MB of onboard flash memory for system software and user programs, and the unit has no plug-in memory expansion. The front panel carries a 4-digit alphanumeric display for status codes. Signal handling includes 3 digital inputs, and the outputs are short-circuit protected. Communication with upper-level controls is available through an RJ-45 connector that supports 10/100 MBaud Ethernet, a Profibus-DP master channel, and an internal backplane path shared with three expansion slots.
In addition to Ethernet and Profibus, the controller includes 2 serial ports that can be configured for RS-232 or RS-485 diagnostics. The output section provides 2 digital outputs and is energized from the common 24 V rail for simple signaling tasks. System protection corresponds to an IP20 rating, so the unit must be installed inside a guarded cabinet to maintain proper operating conditions. Three rear expansion slots accept motion or I/O daughter cards without changing the front footprint, and despite the double slot width the module weighs only 1.3 kg. Its low mass helps when space is limited in compact control cabinets.
Frequently Asked Questions about PPC-R22.1N-T-NN-P1-NN-FW:
Q: What is the required control supply voltage for the PPC-R22.1N-T-NN-P1-NN-FW controller?
A: The control supply voltage for the PPC-R22.1N-T-NN-P1-NN-FW is 24 VDC.
Q: Which Ethernet interface and port are available on the PPC-R22.1N-T-NN-P1-NN-FW?
A: This controller features a 10/100 MBaud Ethernet interface with an RJ-45 port for network connectivity.
Q: How many digital inputs and outputs are available on the PPC-R22.1N-T-NN-P1-NN-FW?
A: The unit comes equipped with 3 digital inputs and 2 digital outputs for basic I/O handling.
Q: What type of display is present on the PPC-R22.1N-T-NN-P1-NN-FW?
A: There is a 4-digit alphanumeric display integrated in this model.
Q: How much onboard flash memory does the PPC-R22.1N-T-NN-P1-NN-FW offer, and is memory expansion included?
A: This unit provides a total of 32 MB of flash memory without any further memory expansion installed.
