PPC-R22.1N-N-Q1-NN-NN-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: 1070170281
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat PPC-R22.1N-N-Q1-NN-NN-FW is a control unit from the PPC Controllers series, featuring a supply voltage of 24 VDC and a maximum current consumption of 1.2 Amps. It offers 3 digital inputs, 2 digital outputs with a 0.5 Amp output current, and provides cross communication via DAQ03. This unit has an IP20 protection rating, a 4-digit alphanumeric display, and comes in a RECO housing design.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The PPC-R22.1N-N-Q1-NN-NN-FW is a control unit produced by Bosch Rexroth Indramat and assigned to the PPC Controllers series. Installed in an electrical cabinet, it provides sequencing and axis coordination for industrial automation equipment. It takes high-level commands and distributes them to connected drives and peripherals.
The unit is powered from a 24 VDC supply, and its logic stages draw up to 1.2 A, which simplifies low-voltage power distribution inside the machine. Three discrete inputs are available, and the controller can accept up to 3 sensor or switch signals without additional interface boards. On the output side, it offers 2 transistor channels, each rated for 0.5 A, so small relays or indicator lamps can be driven directly. Cross Communication via the DAQ03 module supports deterministic data exchange with other PPC nodes, and the link-ring implementation allows the controller to forward telegrams without taxing the main processor. The unused U3 and U4 bays remain covered so airflow through the RECO housing is not obstructed. The unit is not equipped with memory expansion, but two serial links allow external devices to capture process variables or download configuration files.
The RECO-format enclosure is classified as an IP20 device and must therefore be installed inside a protected panel. Front access is aided by the 4-Digit Alphanumeric display, which shows axis status and diagnostic codes at a glance. A programming laptop can connect through the RS-232/RS-485 port for setup, while routine machine communication is handled by the controller’s two unshielded serial channels. Ethernet support is not provided. The housing style is identified as a RECO unit, which gives fixed slot positions for U2 DAQ03, U3 cover, and U4 cover, and the built-in Cross Communication link keeps neighboring controllers synchronized without external switches.
Frequently Asked Questions about PPC-R22.1N-N-Q1-NN-NN-FW:
Q: What communication capabilities does the PPC-R22.1N-N-Q1-NN-NN-FW controller have?
A: The PPC-R22.1N-N-Q1-NN-NN-FW supports cross communication with DAQ03 for advanced data exchange between units.
Q: How many digital inputs are available on the PPC-R22.1N-N-Q1-NN-NN-FW controller?
A: This controller features 3 digital inputs for interfacing with external devices.
Q: What is the required supply voltage for the PPC-R22.1N-N-Q1-NN-NN-FW controller?
A: A supply voltage of 24 VDC is required to operate the PPC-R22.1N-N-Q1-NN-NN-FW.
Q: What type of display does the PPC-R22.1N-N-Q1-NN-NN-FW feature?
A: This model is equipped with a 4-digit alphanumeric display for status and data readout.
Q: How many serial ports and digital outputs does the PPC-R22.1N-N-Q1-NN-NN-FW offer?
A: There are 2 serial ports and two digital output channels on this controller.
