PPC-R22.1N-N-NN-P1-NN-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: 1070170307
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat PPC-R22.1N-N-NN-P1-NN-FW is a control unit from the PPC Controllers series with a RECO housing design and a weight of 1.3 kilograms. It features 3 digital inputs and 2 digital outputs, has a 4-digit alphanumeric display, and supports Profibus Master fieldbus communication. This controller operates on 24 VDC supply voltage and mounts on a TS 35x27x15 DIN rail.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The PPC-R22.1N-N-NN-P1-NN-FW is a compact control unit produced by Bosch Rexroth Indramat for the PPC Controllers series. Installed on machine control panels, it coordinates axis drives, handles local process signals, and exchanges data with higher-level automation systems. By integrating discrete I/O, fieldbus communication, and onboard visualization, the device provides centralized logic execution for packaging, material handling, and assembly lines. This arrangement lets one panel-mounted unit supervise machine sequences, monitor operating states, and pass process data to the wider automation network.
This controller operates from a 24 VDC supply, and its internal electronics consume up to 1.2 A under full processing load. Three digital inputs and two transistor outputs permit direct connection to sensors and actuators, and each output can source 0.5 A for indicator lamps or small switching devices. The front plate includes a 4-digit alphanumeric display that presents operating states and diagnostic codes during startup and routine operation. Communication with distributed devices is handled through a Profibus master port on the DPM01 interface card. Two serial ports are also available: X10 supports RS-232/RS-485, and X16 can be set for RS-232, RS-422, or RS-485.
A molded RECO housing rated at IP20 protects the electronics and mounts on a TS 35×27×15 DIN rail for straightforward cabinet installation. Real-time control is supported by a worst-case output delay of 500 µs, helping the unit respond quickly to changing machine states. Application code and parameters are stored on a 32 MB Compact Flash card, and no additional memory expansion is installed. The controller also accepts power wiring up to 1.5 mm², and its 1.3 kg weight keeps handling manageable when enclosure space is limited.
Frequently Asked Questions about PPC-R22.1N-N-NN-P1-NN-FW:
Q: What type of digital I/O is available on the PPC-R22.1N-N-NN-P1-NN-FW controller?
A: The PPC-R22.1N-N-NN-P1-NN-FW controller features 3 digital inputs and 2 digital outputs.
Q: What type of display does the PPC-R22.1N-N-NN-P1-NN-FW controller have?
A: A 4-digit alphanumeric display is included on this model for status monitoring.
Q: What fieldbus interface does the PPC-R22.1N-N-NN-P1-NN-FW support?
A: This controller is equipped with a Profibus Master fieldbus interface for industrial communication.
Q: What supply voltage is required for the PPC-R22.1N-N-NN-P1-NN-FW controller?
A: The controller operates with a supply voltage of 24 VDC, suitable for standard automation power systems.
Q: What is the capacity and type of memory card included with the PPC-R22.1N-N-NN-P1-NN-FW?
A: This unit comes with a 32 MB Compact Flash memory card pre-installed.
