PPC-R22.1N-N-NN-NN-NN-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: 1070170148
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat PPC-R22.1N-N-NN-NN-NN-FW is a control unit from the PPC Controllers series with a nominal supply voltage of 24 VDC and supply voltage tolerance of -15% to +20%. It features a RECO unit housing design, enclosure size of 83.7 x 192 x 150 mm, and has an IP20 protection rating. The unit supports a maximum current consumption of 1.2 Amps and is rated for operation up to 45 degrees Celsius.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The PPC-R22.1N-N-NN-NN-NN-FW is a modular control unit produced by Bosch Rexroth Indramat within the PPC Controllers series. Designed for multi-axis motion platforms and coordinated machine sequences, the unit supplies real-time command processing to downstream drives and I/O modules in an automated cell. By centralizing position calculation and process logic, the controller streamlines programming and reduces field wiring inside industrial equipment. In this role, it passes motion commands and process states between the machine program and the connected drive system. That arrangement helps keep axis behavior coordinated during positioning, indexing, and repetitive cycle changes.
For reliable logic power, the controller requires a nominal input of 24 VDC, and its regulators tolerate fluctuations of -15% / +20%. Under full processing load, the current drawn does not exceed 1.2 A, so the unit can share a 24 V supply with nearby control devices when the power budget is planned correctly. The enclosure measures 83.7 × 192 × 150 mm, letting it occupy a single slot in a control rack, and the electronics sit in a RECO unit housing that accepts front terminals. A vented cover supports the IP20 rating, which blocks finger contact but requires mounting inside a closed cabinet. Because it does not include memory expansion, user programs remain in the built-in flash rather than on an added storage module. Front terminals also help keep control connections organized in compact cabinet layouts.
This controller is design version 1. During operation, it can be installed in ambient temperatures up to 45 °C without derating, while storage is permitted from -25 °C to 70 °C. Keeping the unit within these temperature limits helps protect the microprocessor and bus connectors from thermal stress and condensation. The compact housing and modest power demand make it practical for packaging, printing, and material-handling systems that use distributed drives and peripheral I/O. Its rack-style format also helps keep cabinet wiring concentrated in one area for a cleaner control layout.
Frequently Asked Questions about PPC-R22.1N-N-NN-NN-NN-FW:
Q: What design version is the PPC-R22.1N-N-NN-NN-NN-FW controller?
A: The PPC-R22.1N-N-NN-NN-NN-FW controller is a Design Version 1 model.
Q: What supply voltage does the PPC-R22.1N-N-NN-NN-NN-FW require?
A: This unit accepts a nominal supply voltage of 24 VDC.
Q: What is the maximum operating temperature for the PPC-R22.1N-N-NN-NN-NN-FW?
A: The PPC-R22.1N-N-NN-NN-NN-FW can operate at temperatures up to 45°C.
Q: What is the maximum current consumption of the PPC-R22.1N-N-NN-NN-NN-FW?
A: The maximum current consumption for this controller is 1.2 A.
Q: What is the protection rating of the PPC-R22.1N-N-NN-NN-NN-FW?
A: This model has a protection rating of IP20, indicating limited protection against dust and no protection against liquids.
