Product Description:

Bosch Rexroth Indramat's PPC-R22.1N-N-N1-N2-V2-FW is a control unit from the PPC Controllers series. Supplied in a RECO housing, the module occupies a compact slot in the drive cabinet and directs multi-axis motion sequences, position latching, and general machine I/O. By combining onboard processing with fieldbus exchange, it lets servo drives, sensors, and actuators execute time-critical steps in coordination with the plant cycle.

The controller operates from a nominal input of 24 VDC, and its base draw remains at 1.2 A, allowing it to be powered from the same low-voltage rail that feeds auxiliary automation hardware. Application code and parameters reside in 32 MB of flash memory, so programs are retained after shutdown without external memory. Three backplane connectors expose 3 expansion slots, so option cards such as the PLS module can be added without increasing enclosure depth. The front panel carries three digital inputs and two digital outputs rated at 0.5 A, giving the unit a small local I/O block for flags or relays. A protection rating of IP20 indicates that the electronics are shielded against accidental finger contact, but the unit must be mounted in a closed control cabinet.

For networked operation, the PPC uses a DeviceNet DNS03 slave interface that communicates at 500 KBaud. This channel transfers up to 64 B In / 64 B Out per scan, and the bus completes a full data refresh every 4 ms, so host controllers can adjust motion states with minimal latency. Physical wiring lands on a 5-pin open-style terminal block, simplifying daisy-chain installation. When the optional PLS card is fitted, the unit provides 32 PLS outputs that are recalculated every 250 µs; this fast update lets downstream drives trigger cam profiles at consistent angles even during rapid acceleration.
