PPC-R22.1N-N-Q1-P1-N1-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
The Bosch Rexroth Indramat PPC-R22.1N-N-Q1-P1-N1-FW is a control unit from the PPC Controllers series, featuring cross communication with DAQ03 capability. This unit is a RECO housing design, standard version, and includes an option card PLS module, type NSW01.
Internal Product Review
The PPC-R22.1N-N-Q1-P1-N1-FW is a control unit with a RECO unit housing design for PPC controller installations. Cross Communication via DAQ03 and the NSW01 PLS option card support clean integration and dependable signal management. The standard design makes the model a strong choice for coordinated machine control.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The PPC-R22.1N-N-Q1-P1-N1-FW is a control unit produced by Bosch Rexroth Indramat for the PPC Controllers series. Positioned on a plant cross-communication network, it processes motion sequences and distributes commands to multiple drives. By executing user programs locally, the module reduces response time and supports packaging, printing, and assembly machines that require synchronized axis control.
A Cross Communication interface designated DAQ03 permits deterministic data exchange among several PPC units, helping position, velocity, and diagnostic data remain consistent across the motion group. The hardware is identified as Design Version 1, which defines the electronic revision and connector arrangement. Expansion for a PLS module is available, and the installed NSW01 card allows camming and electronic gearing tables to be generated inside the controller.
The controller uses a RECO unit housing, which fits the modular format used with adjacent system components. That enclosure style supports compact control assemblies where controllers and adjacent I/O modules are grouped together, keeping cabinet organization orderly and reducing the distance between processing and field signals. It is not equipped with memory expansion, so application code and machine parameters must remain within the onboard storage capacity. The device follows the Standard Design format for this family, supporting a consistent layout for matching system builds.
Wake Industrial can arrange same-day shipping for urgent replacement needs. Quotations for this controller remain valid for 30 days, which helps with maintenance planning and purchasing approval. Customers can use the chat tool available on the website for general questions about type codes or fault indicators.
