The Bosch Rexroth Indramat PPC-R02.2N-N-Q1-NN-NN-FW is a control unit from the PPC Controllers series with a nominal supply voltage of 24 VDC and a maximum power of 52 watts. It offers 3 digital inputs, 2 digital outputs with 0.5 amp output current, and weighs 1.3 kilograms. The unit has an IP20 protection rating and operates within a temperature range of 0 to 45 degrees Celsius.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The PPC-R02.2N-N-Q1-NN-NN-FW is a modular control unit manufactured by Bosch Rexroth Indramat for the PPC Controllers series. It carries design version 2 and belongs to hardware series 2. Through its Cross Communication and DAQ03 interface, the module links drives, sensors, and supervisory computers for coordinated axis and process control within distributed automation cells. It is intended for machine control tasks that require synchronized data exchange between motion components and peripheral devices.
The unit draws a nominal supply of 24 VDC and remains functional across a permissible window of 19.2–30 VDC with up to 4 Vpp ripple. Under full computational and switching load, it caps dissipation at 52 W and will not exceed a line demand of 1.2 A. The internal 24 V I/O bus can source 2.3 A for external sensors, while a separate 5 V rail delivers 3.0 A to logic boards. Three opto-isolated digital inputs accept fast trigger signals, and two transistor outputs provide 0.5 A each for relay coils or status lamps. The controller is supplied without memory expansion, and system-level data is buffered in the onboard RAM. Rack installation uses RMB02.2 carriers that snap to a TS 35 DIN rail, so the card slides directly beside drive modules.
The RECO housing measures 83.7 × 192 × 150 mm and slides into the rail with a keyed backplane connector, leaving enough front clearance for cable bends and connector access. Once in the rack, its enclosure affords a protection rating of IP20, so it must be mounted in a closed cabinet. Continuous service is specified between 0–45 °C, while long-term storage is permissible down to -25 °C and up to 70 °C without performance loss. At only 1.3 kg, the module imposes minimal load on the DIN rail while still supporting stable installation. Its slim housing also helps the controller fit into compact cabinets where rail space is limited.
Frequently Asked Questions about PPC-R02.2N-N-Q1-NN-NN-FW:
Q: What is the nominal supply voltage for the PPC-R02.2N-N-Q1-NN-NN-FW controller?
A: The PPC-R02.2N-N-Q1-NN-NN-FW controller operates at a nominal supply voltage of 24 VDC.
Q: How many digital inputs are available on the PPC-R02.2N-N-Q1-NN-NN-FW controller?
A: This model provides three digital inputs for integration with external devices.
Q: What communication options are supported by the PPC-R02.2N-N-Q1-NN-NN-FW controller?
A: The PPC-R02.2N-N-Q1-NN-NN-FW supports cross communication and DAQ03 for device interfacing.
Q: What is the maximum power consumption of the PPC-R02.2N-N-Q1-NN-NN-FW control unit?
A: Maximum power consumption for this model reaches up to 52 W.
Q: What protection rating does the PPC-R02.2N-N-Q1-NN-NN-FW controller have?
A: The protection rating of the PPC-R02.2N-N-Q1-NN-NN-FW is IP20.
