PPC-R02.2N-N-L2-T2-NN-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911291193
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat PPC-R02.2N-N-L2-T2-NN-FW is a control unit from the PPC Controllers series with a RECO unit housing design. It offers an Ethernet 10 Mb interface (ETH01) and a ControlNet fieldbus slave interface (CNS01). This unit is design version 2 and is not equipped with memory expansion.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The PPC-R02.2N-N-L2-T2-NN-FW is a control unit from the PPC Controllers series produced by Bosch Rexroth Indramat. Mounted in a motion cabinet, the unit supervises multi-axis drives, local sensors, and human-machine interfaces. By executing real-time control cycles that interpret position commands and return status words, it forms the communication bridge between servo hardware and higher-level factory control systems. It is intended for centralized machine control where coordinated drive response and status handling must occur within the same cabinet environment.
In operation, the control unit relies on a front-loaded communication set that is fixed at the factory. An integrated Ethernet 10 Mb interface identified as ETH01 handles basic TCP/IP traffic for parameter transfer, remote diagnostics, and event logging at legacy network speeds. Real-time coordination with drives is assigned to the separate ControlNet fieldbus slave interface CNS01, which exchanges deterministic producer-consumer packets with a scheduled update time. Mechanical integration is simplified by the RECO housing, which allows the card to slide into a common rack and share a power rail with adjacent modules. Because there is no memory expansion, all user programs and motion data blocks must reside in the controller's internal flash. This layout keeps routine Ethernet traffic separate from scheduled motion communication and helps maintain steady data exchange on larger conveyor or gantry systems.
The unit is designated as Design Version 2 within the Series 2 generation of PPC controllers. This revision keeps the same electrical pinout and control call structure used by earlier units, so cabinet wiring and established control behavior remain consistent. Status indication is provided through diagnostic LEDs, allowing the operating state to be checked directly at the front of the module. The unchanged interface arrangement also helps preserve rack layouts where neighboring modules share the same power rail and front access path. Port placement remains consistent, which supports orderly cable routing in tightly packed control cabinets.
Frequently Asked Questions about PPC-R02.2N-N-L2-T2-NN-FW:
Q: What design version is the PPC-R02.2N-N-L2-T2-NN-FW control unit?
A: The PPC-R02.2N-N-L2-T2-NN-FW is Design Version 2.
Q: What Ethernet connectivity is available on the PPC-R02.2N-N-L2-T2-NN-FW controller?
A: This model includes an Ethernet 10 Mb interface with the ETH01 option.
Q: Which fieldbus interface is supported by the PPC-R02.2N-N-L2-T2-NN-FW?
A: The controller provides a ControlNet fieldbus slave interface designated as CNS01.
Q: What housing design does the PPC-R02.2N-N-L2-T2-NN-FW feature?
A: It is built in a RECO unit housing design.
Q: Is memory expansion available on the PPC-R02.2N-N-L2-T2-NN-FW controller?
A: The PPC-R02.2N-N-L2-T2-NN-FW does not support memory expansion.
