PPC-R02.2N-N-V2-T2-NN-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat PPC-R02.2N-N-V2-T2-NN-FW is part of the PPC Controllers series and is a control unit with a RECO housing design. It features an Ethernet 10 Mb interface (ETH01) and a DeviceNet fieldbus slave interface (DNS03). This unit is design version 2 and does not include memory expansion.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The PPC-R02.2N-N-V2-T2-NN-FW is a control unit manufactured by Bosch Rexroth Indramat and assigned to the PPC Controllers series. Installed in a multi-axis drive rack, it interprets user programs, issues deterministic command words to servo inverters, collects feedback from sensors, and passes diagnostics to supervisory computers. It acts as the coordination layer between machine logic and the drive hardware, so motion commands can be distributed with predictable timing. By concentrating these control tasks in one module, it reduces point-to-point wiring and helps automated equipment respond consistently during synchronized starts, stops, and position changes in machine tools, packaging stations, transfer systems, and other factory automation lines.
The controller uses design version 2. For plant-wide networking, it provides a 10 Mb Ethernet interface that supports standard TCP/IP services, and this port is identified as ETH01. Machine-level communication is handled by a DeviceNet fieldbus slave interface listed under code DNS03, allowing cyclic process data to move under CIP rules. This combination lets supervisory computers exchange recipes, status data, and diagnostics over Ethernet while field devices remain on DeviceNet for real-time I/O traffic, so the controller can link PLCs, HMIs, drives, and intelligent sensors without adding a separate gateway module.
The electronics are housed in a RECO unit, allowing the board stack to slide into a backplane that carries power and high-speed bus signals. There is no memory expansion, so user programs, operating parameters, and motion routines remain stored in the internal flash rather than on removable memory hardware. The fixed memory arrangement keeps software storage inside the module and avoids dependence on extra plug-in media. The rack format follows the timing, addressing, and diagnostic structure used by this controller platform, which helps neighboring modules communicate through the same system architecture and keeps the control cabinet layout orderly when several drive and interface modules share a common backplane.
Frequently Asked Questions about PPC-R02.2N-N-V2-T2-NN-FW:
Q: What type of Ethernet connectivity does the PPC-R02.2N-N-V2-T2-NN-FW controller offer?
A: The PPC-R02.2N-N-V2-T2-NN-FW controller features an Ethernet 10 Mb interface labeled as ETH01.
Q: Which fieldbus interface is included in the PPC-R02.2N-N-V2-T2-NN-FW controller?
A: This unit provides a DeviceNet fieldbus slave interface, identified as DNS03.
Q: What housing design is used for the PPC-R02.2N-N-V2-T2-NN-FW controller?
A: The PPC-R02.2N-N-V2-T2-NN-FW is built with the RECO housing design.
Q: Is memory expansion available on the PPC-R02.2N-N-V2-T2-NN-FW controller?
A: No memory expansion is included with this model; it comes without additional memory options.
Q: Which design version is the PPC-R02.2N-N-V2-T2-NN-FW controller?
A: The PPC-R02.2N-N-V2-T2-NN-FW is a Design Version 2 device from Bosch Rexroth Indramat.
