Product Description:

The PPC-R02.2N-N-N1-V2-T2-FW is a control unit from Bosch Rexroth Indramat in the PPC Controllers series. The module executes motion sequences and axis coordination in industrial automation cells, acting as the processing node between higher-level PLC instructions and drive amplifiers. It provides centralized control of multiple servo axes from a single rack slot, which helps keep machine timing consistent across linked movements. By handling command generation and I/O routing on a compact board, the unit supports synchronized operation without requiring a separate industrial PC for basic motion tasks.

Internally, this unit is classified as Design version 2. Network connectivity is provided through the Ethernet 10 Mb interface for diagnostics and program transfer. For machine-level communication, it includes a DeviceNet fieldbus slave interface with the identifier DNS03, allowing direct exchange of process data with decentralized sensors and drives. The Ethernet port supports UDP messaging for status capture, while the DeviceNet node supports polling and strobed I/O modes used by compatible drive systems. Mechanical integration uses the RECO unit housing, so the electronics slide into standardized Rexroth racks without additional brackets.

Additional resources are managed through the controller's option slot. In this version, it carries the Option Card PLS module with code NSW01, which supplies microsecond-level trigger outputs for coordinated motion tasks such as latching position events or issuing synchronized cut commands. The board is supplied with no memory expansion, so user data remains in the base SRAM. The unit is built on the Series 2 hardware platform, and the dedicated latch path bypasses main bus arbitration to keep output-capture jitter below one microsecond during synchronized operation.
