PPC-R02.2N-N-N1-N2-V2-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat PPC-R02.2N-N-N1-N2-V2-FW is a control unit from the PPC Controllers series with a RECO unit housing design. It features a DeviceNet fieldbus slave interface and comes with an option card PLS module. This unit is design version 2 and is not equipped with memory expansion.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The PPC-R02.2N-N-N1-N2-V2-FW is a modular control unit developed by Bosch Rexroth Indramat and supplied within the PPC Controllers series. Designed for DIN-rail installation in multi-axis motion platforms, the unit provides central coordination of drive parameters, interpolation tasks, and process sequences in industrial automation cells. By using interchangeable memory carriers for application software and communicating over real-time fieldbus networks, it acts as the command layer between supervisory PLCs, local I/O, and servo amplifiers.
Its communication backbone is the DeviceNet fieldbus slave interface, which lets the controller operate as a subordinate node for cyclic I/O exchange and explicit messaging with a master scanner. The controller is housed in a RECO unit, so its connectors, status LEDs, and back-plane jumpers follow the standardized Rexroth Euro card format used in compact control racks. Expandability for application-specific motion logic is provided by the Option Card PLS module, which supports position latch and cam switch functions without external hardware. Compatibility is tied to Design Version 2, so the controller must be used with matching drive software and engineering tools. The base hardware is a Control Unit, so it contains the CPU, fieldbus circuitry, and memory sockets while relying on external drives for power electronics.
In this configuration, there is no memory expansion, so the internal flash stores the operating system, user parameters, and diagnostic buffers. Identifier DNS03 classifies the DeviceNet interface for node addressing and baud-rate selection in distributed conveyor, press, and packaging lines. When combined with axis drives from Series 2, the controller maintains synchronous position loops while staying within the noise-immunity limits expected in 24 V control cabinets. The service interfaces and diagnostic LEDs follow the same general operating structure used across this controller platform.
Frequently Asked Questions about PPC-R02.2N-N-N1-N2-V2-FW:
Q: What type of fieldbus interface is provided on the PPC-R02.2N-N-N1-N2-V2-FW?
A: The PPC-R02.2N-N-N1-N2-V2-FW controller features a DeviceNet fieldbus slave interface under the DNS03 specification.
Q: What design version is the PPC-R02.2N-N-N1-N2-V2-FW controller?
A: This control unit is classified as a Design Version 2 model.
Q: What housing design does the Bosch Rexroth Indramat PPC-R02.2N-N-N1-N2-V2-FW have?
A: The PPC-R02.2N-N-N1-N2-V2-FW uses the RECO unit housing design for its enclosure.
Q: Is there a memory expansion equipped in the PPC-R02.2N-N-N1-N2-V2-FW controller?
A: The controller does not come with a memory expansion feature installed.
Q: Does the PPC-R02.2N-N-N1-N2-V2-FW come with any option cards installed?
A: This model includes an Option Card PLS module as part of its configuration.
