Product Description:

Bosch Rexroth Indramat manufactures the PPC-R01.2N-N-Q1-FW, a control unit in the PPC Controllers series that executes real-time positioning commands and handles logical interlocks for distributed drive packages. The module links to higher-level PLCs through Cross Communication and DAQ03 channels, allowing deterministic data exchange between neighboring controllers and motion axes during synchronized machine operation. Housed as a RECO unit, it slots onto a backplane without additional cabling, which supports compact installation in packaging lines, pick-and-place cells, and material flow systems that demand coordinated axis behavior.

The controller draws a rated supply of 24 VDC and is protected to IP20, so it must be installed inside a cabinet free of conductive dust or moisture. Three digital inputs accept field signals while two transistor outputs issue control flags; each input channel requires only 10 mA, so sensor loading remains low. A dedicated bus section can deliver up to 52 W of auxiliary power, divided between a 5 V rail that sources 3.0 A for logic boards and a 24 V rail that can provide 2.3 A to external relays. Peak module demand stays below 0.7 A, which keeps power supply sizing straightforward and allows multiple controllers to share the same direct-current feed without exceeding fuse ratings.

The compact form factor supports dense cabinet layouts: width is only 41.5 mm, height reaches 192 mm, and depth extends to 150 mm. At just 1.1 kg, the unit adds little mechanical load to DIN rails and supports straightforward handling during installation. Its relay stage switches up to 150 mA, while the transistor output bank can source 0.5 A for pilot valves or optical indicators. The slim enclosure also leaves room for adjacent modules and cable routing in narrow cabinets.
