Product Description:

Bosch Rexroth Indramat manufactures the MSK101E-0200-NN-M3-AG0-NNNN servomotor for the MSK IndraDyn S Synchronous Motors series. It is an IndraDyn S synchronous servomotor for packaging lines, gantry axes, and general-purpose automation cells. The motor converts drive command current from Rexroth controllers into precise shaft torque and position, supporting dynamic motion profiles with closed-loop feedback. This operating principle helps the axis respond quickly to changing speed and position commands during automated cycles.

Cooling relies on natural convection, so mounting clearances must permit vertical airflow around the stator housing. Feedback is carried through a Hiperface interface, and this serial bidirectional link transmits position, speed, and electronic motor data to the drive. Inside the motor, the sensor delivers 16 signal periods per mechanical revolution, and the capacitive scanning principle helps resist magnetic dust and oil films. A multiturn absolute counter tracks rotations even when power is removed, which eliminates homing sequences after startup. The housing is rated IP65, which blocks dust and water jets. The size 101 frame, E length, and winding code 0200 are matched to M3-class inverters.

Operation is permitted from 0 to 40 °C, matching typical cabinet climates in packaging and printing lines. Torque is transmitted through a plain shaft, allowing couplings or shrink discs to be mounted without key slots or taper pins. Phase conductors attach on the power connector located on the A-side, which keeps motor cables away from moving machine members. The motor is supplied without a holding brake, so any load-holding requirement must be satisfied by drive torque or an external clamp. Class 155 insulation allows the stator to reach elevated temperatures while maintaining dielectric strength during continuous duty.
