Product Description:

The MSK101E-0200-FN-S1-BG0-NNNN is a synchronous servo motor manufactured by Bosch Rexroth Indramat for the MSK IndraDyn S Synchronous Motors series. In automated cells, it converts drive output into accurately regulated rotary motion for positioning tables, feed axes, or coordinated line shafts. The unit follows the standard design configuration, allowing it to fit machine frames already prepared for liquid-cooled MSK drives and to operate as a compact closed-loop axis motor.

Thermal management is handled through liquid cooling, which circulates coolant inside the stator jacket and keeps winding temperature within limits during continuous duty. Feedback travels on the Hiperface interface, letting the drive read absolute rotor angle over one hybrid cable and maintain stable commutation at low and high speed. Position data comes from an optical sensor that resolves 128 signal periods per revolution, and this resolution supports tight speed and position loops in indexing and interpolation tasks. The encoder is single-turn, so it reports angle within one rotation and needs a reference move for multi-turn counts. The motor is built without a holding brake, so external locks or closed-loop torque must secure the load when power is removed.

From the connection side, power enters on the B-side, keeping the cable bundle clear of neighboring axes and helping cable routing stay organized in compact machine bays. Mechanical drive is transmitted through a plain shaft, allowing backlash-free coupling with clamped hubs and other direct-drive connections. The stator lamination stack corresponds to motor size 101, which suits mid-range gantry or press drives while remaining within a 100-series footprint. Electrical behavior is set by the 0200 winding code, which matches the motor to compatible MSK drive inverters and gives the drive the expected resistance and inductance values during current control.
