MSK101D-0200-NN-S1-LG2-NNNN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911338906
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
5 Minutes
45 Seconds
The Bosch Rexroth Indramat MSK101D-0200-NN-S1-LG2-NNNN is part of the MSK IndraDyn S Synchronous Motors series and features a 101 size, D length standard design. This synchronous servomotor uses natural convection cooling, has a plain shaft, and comes with an electrically-released holding brake with a torque of 70 Nm. It includes a Hiperface singleturn optical encoder with a 128 signal period resolution and a left-side power connector.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK101D-0200-NN-S1-LG2-NNNN is an IndraDyn S synchronous servomotor manufactured by Bosch Rexroth Indramat and included in the MSK IndraDyn S Synchronous Motors series. The unit converts drive current into precise rotary motion for indexing tables, gantry axes, and other industrial automation tasks that need tight speed and position control. Its synchronous design allows the paired drive to maintain responsive acceleration and accurate positioning during repeated motion cycles. This makes the motor suitable for applications that depend on stable torque output and repeatable axis movement.
Thermal management for this unit is based on natural convection, so the housing must remain unobstructed and free airflow is required because no forced fan is included. The motor uses a standard design, so mounting dimensions remain consistent with other MSK models of the same rating. For fail-safe stops, it is supplied with a holding brake that is electrically released, and the brake can clamp the shaft with 70 Nm of static torque to help prevent load movement during power loss. Feedback signals are exchanged through a Hiperface interface, and internal interpolation delivers 128 signal periods per mechanical revolution for accurate velocity regulation.
The position sensor uses an optical scanning principle and is configured as a single-turn device, so it transmits absolute angle information within one revolution without multi-turn tracking. The motor has a 101 frame size and a D length stator section, which help determine the required mounting space. Power leads exit on the left side of the stator, which can simplify cable routing when the motor is mounted to right-hand machine walls. A plain shaft is provided for direct coupling to gearboxes or timing pulleys, and the electromagnetic circuit uses winding code 0200 for operation with compatible 300 V DC bus drive controllers.
Frequently Asked Questions about MSK101D-0200-NN-S1-LG2-NNNN:
Q: What type of shaft does the MSK101D-0200-NN-S1-LG2-NNNN motor have?
A: The MSK101D-0200-NN-S1-LG2-NNNN motor uses a plain shaft for coupling with mechanical systems.
Q: What kind of holding brake and torque does the MSK101D-0200-NN-S1-LG2-NNNN motor have?
A: This model features an electrically-released holding brake with a torque rating of 70 Nm.
Q: How is the MSK101D-0200-NN-S1-LG2-NNNN motor cooled during operation?
A: The cooling method for this motor is natural convection and requires Cooling FN per specification.
Q: What type of encoder and interface does the MSK101D-0200-NN-S1-LG2-NNNN motor use?
A: An optical singleturn encoder with Hiperface interface and 128 signal periods is built into this motor.
Q: Where is the power connector located on the MSK101D-0200-NN-S1-LG2-NNNN motor?
A: The power connector for this motor is located on the left side for convenient electrical connection.
