MSK101D-0200-NN-S1-BP2-NNNN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911316420
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
4 Minutes
10 Seconds
The Bosch Rexroth Indramat MSK101D-0200-NN-S1-BP2-NNNN is an IndraDyn S Synchronous Servomotor from the MSK IndraDyn S Synchronous Motors series. It uses natural convection cooling and features a Hiperface optical encoder with 128 signal periods and singleturn capability. This standard design servomotor includes a shaft with keyway, an electrically-released holding brake with a torque of 70 Nm, and a B-side power connector.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK101D-0200-NN-S1-BP2-NNNN servo motor is manufactured by Bosch Rexroth Indramat and belongs to the MSK IndraDyn S Synchronous Motors series. As an IndraDyn S synchronous servo motor, it supplies accurately controlled torque and speed for positioning tables, gantries, and other motion axes used in automated equipment. The unit uses natural convection cooling and carries a keyed output shaft that mates directly with couplings or pulleys. An electrically released holding brake is fitted to secure loads when power is removed, and an optical feedback device supports closed-loop operation. It is suitable for packaging, handling, and indexing equipment where repeatable acceleration and stopping are required.
Core mechanical and electrical dimensions are set by the motor size 101 and the length code D, which provide a larger active stack without changing the mounting interface. The winding code 0200 matches the phase resistance and inductance to standard IndraDrive voltage classes so the motor can reach rated torque under the intended operating conditions. Thermal energy is removed through natural convection, so installation must allow unrestricted ambient airflow to meet the cooling requirement for this model. The power connector is mounted on the B-side, which can simplify cable routing in cabinets where drives sit below the axis. A standard housing and a keyed shaft transfer design torque without additional clamping features.
Position feedback and holding capability are handled by an optical encoder that communicates over Hiperface and generates 128 signal periods per turn. Its single-turn layout reports absolute rotor position within one revolution, allowing immediate commutation on startup. For load holding, the electrically released brake provides 70 Nm of static torque so vertical or suspended loads can remain stationary during a power loss. The encoder also provides immediate position availability after power-up, which helps the drive establish rotor orientation without waiting for a homing cycle in single-revolution applications.
Frequently Asked Questions about MSK101D-0200-NN-S1-BP2-NNNN:
Q: What shaft type does the MSK101D-0200-NN-S1-BP2-NNNN motor use?
A: This model is equipped with a shaft featuring a keyway for secure mechanical coupling.
Q: What type and resolution of encoder does the MSK101D-0200-NN-S1-BP2-NNNN utilize?
A: The MSK101D-0200-NN-S1-BP2-NNNN employs an optical encoder with Hiperface interface and a resolution of 128 signal periods.
Q: How is the MSK101D-0200-NN-S1-BP2-NNNN motor cooled?
A: Natural convection is used for cooling, so no additional forced cooling is required for this unit.
Q: What are the features of the holding brake on the MSK101D-0200-NN-S1-BP2-NNNN motor?
A: A holding brake with 70 Nm of torque, which is electrically-released, is included in this model.
Q: Where is the power connector positioned on the MSK101D-0200-NN-S1-BP2-NNNN motor?
A: The power connector for this motor model is located on the B-side of the unit.
