MSK101D-0200-NN-S1-BG2-NNNN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911325602
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
3 Minutes
41 Seconds
The Bosch Rexroth Indramat MSK101D-0200-NN-S1-BG2-NNNN is part of the MSK IndraDyn S Synchronous Motors series and uses natural convection cooling. This standard design servomotor features a plain shaft, B-side power connector, and an electrically-released holding brake with a torque of 70 Nm. The encoder interface uses Hiperface technology with singleturn optical resolution of 128 signal periods.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK101D-0200-NN-S1-BG2-NNNN belongs to the MSK IndraDyn S Synchronous Motors series produced by Bosch Rexroth Indramat. As an IndraDyn S synchronous servo motor, it converts electrical energy into precisely controlled torque and speed for positioning axes, packaging modules, and other industrial automation tasks that require high dynamic accuracy. This operating principle supports fast acceleration, stable speed control, and repeatable motion in coordinated machine cycles. The motor uses a single-turn position sensor, which reports absolute rotor angle within one mechanical revolution for applications that reference position at startup.
Cooling is handled by natural convection, so heat leaves through the housing surface without auxiliary fans and the motor should be installed where free airflow is available. This approach reduces external cooling hardware and keeps the motor envelope simpler in installations with open air circulation. Feedback is transferred through a Hiperface interface, allowing bidirectional data exchange between the motor and drive for monitoring and closed-loop control. The encoder provides 128 signal periods, and its optical scanning principle avoids mechanical contact inside the feedback system. An electrically released holding brake supplies 70 Nm of static torque so the shaft can remain stationary when power is removed.
Mechanical sizing follows code 101, which matches the motor to the corresponding flange pattern and current class in the product line. The electromagnetic layout uses winding code 0200, which gives the resistance and inductance values expected by compatible drive algorithms. Power cables are routed through a B-side power connector at the non-drive end, helping keep wiring clear of the drive shaft and adjacent coupling components. The motor also has a standard design housing, length code D, and a plain shaft for clamp-style couplings. A plain shaft suits friction-locked hubs and avoids the stress concentration that can come with keyed connections in cyclic servo duty.
Frequently Asked Questions about MSK101D-0200-NN-S1-BG2-NNNN:
Q: What encoder interface is provided on the MSK101D-0200-NN-S1-BG2-NNNN motor?
A: This motor uses a Hiperface encoder interface for connection to feedback devices.
Q: Does the MSK101D-0200-NN-S1-BG2-NNNN motor have a holding brake and what is its torque rating?
A: The MSK101D-0200-NN-S1-BG2-NNNN is equipped with a holding brake that is electrically released and provides 70 Nm of torque.
Q: How is the MSK101D-0200-NN-S1-BG2-NNNN motor cooled?
A: This servomotor features natural convection cooling and requires Cooling FN for operation.
Q: Where is the power connection located on the MSK101D-0200-NN-S1-BG2-NNNN servomotor?
A: The power connector on the MSK101D-0200-NN-S1-BG2-NNNN is located on the B-side of the motor.
Q: What type of shaft does the MSK101D-0200-NN-S1-BG2-NNNN motor use?
A: This model features a plain shaft type for straightforward coupling with mechanical systems.
