MSK101D-0200-NN-M3-RG2-NNNN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911341368
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
6 Minutes
57 Seconds
The Bosch Rexroth Indramat MSK101D-0200-NN-M3-RG2-NNNN is part of the MSK IndraDyn S Synchronous Motors series and features a natural convection cooling method with IP65 protection. This servomotor comes with a right-side power connector, plain shaft, and a holding brake that provides 70 Nm of torque. Its Hiperface encoder uses capacitive multiturn absolute technology with 16 signal periods resolution.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK101D-0200-NN-M3-RG2-NNNN is an IndraDyn S synchronous servomotor produced by Bosch Rexroth Indramat for the MSK IndraDyn S Synchronous Motors series. It provides controlled torque and speed for tooling, conveyors, and pick-and-place axes in automated production cells, where the drive controller continuously corrects motion. The motor uses frame size 101 with the longer D housing, which provides more active length than shorter housings in the same platform. That combination suits repetitive indexing, synchronized transfer, and other servo-driven machine functions that require stable response through frequent starts and stops.
Heat is removed by natural convection, so the installation should leave free airflow around the cooling fins. The housing is sealed to IP65, which helps keep dust and low-pressure water jets away from internal parts during normal industrial service. Insulation class 155 allows the winding system to tolerate elevated copper temperature, and the motor maintains nominal parameters in ambient temperatures from 0 to 40 °C. A plain shaft supports direct coupling, the power connector is positioned on the right side, and winding code 0200 is intended for use with standard IndraDrive amplifiers. This layout keeps the mechanical interface simple and can ease cable routing where nearby machine members leave limited clearance.
Position feedback is transmitted over a Hiperface interface using a capacitive sensor system with 16 signal periods per mechanical revolution. This arrangement gives the drive the rotor angle information needed for accurate speed regulation and precise axis positioning. An electrically released brake provides 70 Nm of static torque, which helps secure vertical or suspended loads when power is removed. Because the encoder reports absolute position, the control system does not need to re-establish the shaft angle with an incremental reference pulse after every stop. Multiturn absolute counting preserves position data after shutdown, so the stored shaft position remains available when the system powers back up.
Frequently Asked Questions about MSK101D-0200-NN-M3-RG2-NNNN:
Q: What type of encoder is used in the MSK101D-0200-NN-M3-RG2-NNNN motor?
A: This model uses a multiturn absolute encoder with Hiperface interface for precise position tracking.
Q: How is the MSK101D-0200-NN-M3-RG2-NNNN motor cooled?
A: It operates with natural convection cooling and requires Cooling FN for optimal performance.
Q: What is the holding brake torque and release type for the MSK101D-0200-NN-M3-RG2-NNNN?
A: The holding brake on this model offers a torque of 70 Nm and is electrically-released.
Q: What is the protection rating of the MSK101D-0200-NN-M3-RG2-NNNN motor?
A: The MSK101D-0200-NN-M3-RG2-NNNN has a protection rating of IP65, making it resistant to dust and water spray.
Q: What shaft type and power connector orientation does the MSK101D-0200-NN-M3-RG2-NNNN provide?
A: This version features a plain shaft and a right-side power connector design.
