The Bosch Rexroth Indramat MSK101D-0200-NN-M3-BP0-NNNN is part of the MSK IndraDyn S Synchronous Motors series and features natural convection cooling and a standard design. This synchronous servomotor uses a Hiperface encoder with capacitive technology and multiturn absolute functionality, and has an IP65 protection rating. The motor is size 101 with D length, operates in ambient temperatures up to 40°C, and has a shaft with keyway.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK101D-0200-NN-M3-BP0-NNNN is a synchronous servo motor manufactured by Bosch Rexroth Indramat for the MSK IndraDyn S Synchronous Motors series. In automated production lines, it works with a drive controller to supply controlled torque and velocity to positioning, feed, and handling axes. The motor integrates a multiturn absolute feedback device so the drive can monitor rotor position over multiple revolutions, enabling accurate closed-loop motion control in machinery that demands precise repeatability. This arrangement is useful on axes that need position retention across repeated revolutions and controlled restarts after power cycles.
Heat generated by the windings is removed through natural convection, so no external blower or liquid circuit is required. The housing surface dissipates continuous losses during normal operation. Position data travel to the drive over the Hiperface interface, allowing power-on commutation and parameter storage inside the encoder. The encoder provides 16 signal periods, which the controller interpolates for fine speed regulation. This feedback arrangement supports stable commutation at startup and smooth speed regulation during direction changes. The motor has an IP65 rating, and the stator and encoder components are intended for ambient temperatures of 0–40 °C.
The motor has size 101 and length code D, a combination suited to medium-frame machines where moderate inertia is acceptable. Torque is transmitted through a shaft with keyway, which supports rigid coupling to pulleys or gearboxes. The keyed shaft also helps transmit torque without relying only on friction at the coupling. The winding insulation uses class 155, allowing winding temperatures up to 155 °C before degradation. Electrical behavior matches winding code 0200, which corresponds to resistance and inductance values used by compatible Rexroth drives. It uses standard design hardware with a B-side power connector and capacitive multiturn encoder technology. The motor is supplied without a holding brake, so static holding must be provided by drive torque or external mechanics when the axis is stopped.
Frequently Asked Questions about MSK101D-0200-NN-M3-BP0-NNNN:
Q: What type of encoder does the MSK101D-0200-NN-M3-BP0-NNNN motor utilize?
A: The MSK101D-0200-NN-M3-BP0-NNNN uses a multiturn absolute encoder with capacitive technology for precise position detection.
Q: How is the MSK101D-0200-NN-M3-BP0-NNNN motor cooled?
A: This model features natural convection cooling and operates without external fans or forced cooling systems.
Q: What shaft type does the MSK101D-0200-NN-M3-BP0-NNNN offer?
A: The shaft on this motor is equipped with a keyway for secure mechanical coupling.
Q: Does the MSK101D-0200-NN-M3-BP0-NNNN motor have a holding brake?
A: The holding brake is not included with the MSK101D-0200-NN-M3-BP0-NNNN.
Q: What is the protection rating of the MSK101D-0200-NN-M3-BP0-NNNN motor?
A: This servomotor carries an IP65 protection rating, making it dust tight and protected against water jets.
