Product Description:

The MSK101D-0200-NN-M3-AP0-NNNN belongs to the MSK IndraDyn S synchronous motors series from Bosch Rexroth Indramat. The unit is an AC servomotor that delivers tightly regulated torque and position feedback for indexing tables, packaging axes, and other motion tasks in automated machines. As a standard-design motor, it pairs with Rexroth drives through its integrated encoder and supports cabinet-free mounting because of its sealed construction. Within an installation, it converts electrical energy from the drive into rotational motion that can be precisely programmed by the control system. That arrangement supports repeatable movement on servo axes that must start, stop, and reposition with minimal deviation.

Heat removal relies on passive airflow because the motor uses natural convection, eliminating the need for external blowers or liquid circuits. The housing carries an IP65 protection rating, so dust and low-pressure water jets do not interfere with internal windings or bearings. Position data is exchanged with the drive over the Hiperface interface, and the built-in sensor scans 16 signal periods per mechanical revolution to generate high-resolution feedback. Because the sensing principle is capacitive, feedback remains stable under vibration and temperature changes. All power conductors exit on the A-side connector, which helps simplify cable routing in multi-axis gantries and other compact machine layouts.

The encoder stores absolute position across power cycles, and its multiturn absolute feedback supports startup without a homing sequence. Output torque is transferred through a shaft with a keyway, allowing rigid coupling to pulleys or gear stages. Continuous service is permitted in ambient temperatures from 0–40 °C. The windings use insulation class 155, which allows elevated internal temperatures without premature aging. The motor also has a length code D stator, size 101 frame, winding code 0200, and no holding brake.
