MSK100D-0350-NN-M2-BG2-RNNN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911332725
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
3 Minutes
53 Seconds
The Bosch Rexroth Indramat MSK100D-0350-NN-M2-BG2-RNNN is an IndraDyn S Synchronous Servomotor from the MSK series, featuring natural convection cooling and a motor size of 100 with length D. It has an IP65 protection rating, a plain shaft, and comes with an electrically-released holding brake providing a holding torque of 70 Nm. This motor uses an EnDat2.1 multiturn absolute optical encoder with a resolution of 2048 signal periods and is designed for operating ambient temperatures from 0 to 40°C.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK100D-0350-NN-M2-BG2-RNNN is a brushless IndraDyn S synchronous servomotor produced by Bosch Rexroth Indramat. In packaging lines, pick-and-place units, and machining centers, it converts regulated three-phase drive current into precise rotary motion for position, speed, and torque control. The motor is intended to work with compatible IndraDrive controllers, and its rear-mounted hybrid connector helps keep power and feedback wiring compact at the machine. This layout supports installations where cable routing space is limited and direct motor integration is preferred. That arrangement reduces the number of separate motor-side interfaces and suits dense axis groupings.
For heat dissipation, the motor relies on natural convection, so surface fins release heat to the surrounding air without auxiliary fans. Feedback is transmitted through the EnDat2.1 serial interface, and the built-in optical scanning system provides 2048 signal periods per revolution for accurate position evaluation. An electrically released brake supplies 70 Nm of holding torque to keep the shaft stationary during standby or emergency stops. The enclosure has an IP65 rating that protects internal parts from dust and low-pressure water jets, and the plain shaft supports flexible coupling selection. Because cooling is passive, the motor can be used where external airflow is undesirable or unavailable.
The encoder includes multiturn absolute functionality, allowing the drive to retain position information across power cycles. Frame size 100 is paired with motor length D, giving the unit a larger housing within this series for applications that need higher torque in this platform. Continuous operation is permitted in ambient temperatures from 0 to 40 °C, and winding code 0350 matches the electrical characteristics expected by compatible drive controllers. Increased concentricity supports running accuracy, and the B-side power connection helps separate cable paths around the motor body. This combination supports repeatable motion on axes that must restart without a homing cycle after brief power interruptions.
Frequently Asked Questions about MSK100D-0350-NN-M2-BG2-RNNN:
Q: What type of encoder does the MSK100D-0350-NN-M2-BG2-RNNN motor feature?
A: The MSK100D-0350-NN-M2-BG2-RNNN motor uses a multiturn absolute optical encoder with EnDat2.1 interface and 2048 signal periods of resolution.
Q: Does the MSK100D-0350-NN-M2-BG2-RNNN motor have a holding brake?
A: This servomotor is equipped with a holding brake that is electrically-released and provides 70 Nm of holding torque.
Q: What is the protection rating of the MSK100D-0350-NN-M2-BG2-RNNN motor?
A: The MSK100D-0350-NN-M2-BG2-RNNN offers IP65 protection, safeguarding it against dust ingress and water jets.
Q: How is the MSK100D-0350-NN-M2-BG2-RNNN motor cooled?
A: Natural convection is the cooling method used for this model, operating without forced airflow or integrated fans.
Q: What shaft type does the MSK100D-0350-NN-M2-BG2-RNNN motor use?
A: The shaft on this model is a plain shaft type, making it suitable for applications where keyed connections are not required.
