MSK100D-0300-NN-S1-BP0-NNNN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911311230
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat MSK100D-0300-NN-S1-BP0-NNNN is part of the MSK IndraDyn S Synchronous Motors series. This standard design servomotor uses natural convection cooling and features a shaft with keyway and a B-Side power connector. It is equipped with a Hiperface optical singleturn encoder with 128 signal periods and does not have a holding brake.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK100D-0300-NN-S1-BP0-NNNN is a servo motor built by Bosch Rexroth Indramat in the MSK IndraDyn S Synchronous Motors series. It is an IndraDyn S synchronous servomotor for closed-loop motion axes in packaging machinery and pick-and-place gantries. It combines a 100-frame stator, length code D, and winding code 0300 to balance torque density with manageable thermal output. In service, the motor works with a matching servo drive to convert commanded current into controlled torque, speed, and angular position on dynamic production axes. This arrangement supports fast acceleration and precise position control while keeping the motor compact enough for tightly spaced machine layouts.
Thermal management relies on natural convection, so the motor dissipates heat through its housing without auxiliary fans or liquid circuits. That cooling method reduces external hardware, but the installation still needs free air movement around the frame to carry heat away. Rotor position is reported through a Hiperface interface that sends both absolute and incremental data to the drive. Inside the feedback unit, an optical scanning system generates 128 signal periods per revolution, and the encoder is configured as a single-turn device so the drive receives one absolute position value for each mechanical revolution. The combined feedback channels support commutation, speed regulation, and position monitoring without a separate external measuring device on many standard axes.
Because the motor is supplied without a holding brake, any static load must be secured by external mechanics or by controlled drive torque when power is removed. The shaft has a keyway for torque transfer, and the electrical terminations exit on the B-side power connector, which helps route cables toward the rear of the machine. A keyed shaft can be paired with couplings or pulleys that require positive torque transmission under changing acceleration loads. The motor length D code and motor size 100 frame establish the mounting envelope and flange dimensions used for installation. Rear-oriented connector exit can also reduce cable bend stress when the motor is mounted inside compact guarding or along a linear module.
Frequently Asked Questions about MSK100D-0300-NN-S1-BP0-NNNN:
Q: What cooling method does the MSK100D-0300-NN-S1-BP0-NNNN motor utilize?
A: The MSK100D-0300-NN-S1-BP0-NNNN servo motor features natural convection cooling, operating without external fans.
Q: Does the MSK100D-0300-NN-S1-BP0-NNNN include a holding brake?
A: This model comes without a holding brake installed.
Q: What type of encoder is present on the MSK100D-0300-NN-S1-BP0-NNNN motor?
A: It uses a singleturn optical encoder with Hiperface interface for feedback.
Q: Where is the power connector located on the MSK100D-0300-NN-S1-BP0-NNNN motor?
A: The power connector on this motor is positioned on the B-side.
Q: What kind of shaft does the MSK100D-0300-NN-S1-BP0-NNNN motor have?
A: This servo motor is designed with a shaft that incorporates a keyway.
