The Bosch Rexroth Indramat MSK100D-0300-NN-M1-AG2-NNNN is part of the MSK IndraDyn S Synchronous Motors series and features a D length, size 100 motor design. This standard IndraDyn S synchronous servomotor has natural convection cooling and a plain shaft with an A-side power connector. It includes a multiturn absolute optical encoder with Hiperface interface and a holding brake torque of 70 Nm.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK100D-0300-NN-M1-AG2-NNNN is a synchronous servo motor produced by Bosch Rexroth Indramat within the MSK IndraDyn S Synchronous Motors series. This motor provides closed-loop rotary actuation for CNC tables, packaging axes, and transfer lines that require precise position and speed control. As part of a drive system, it interfaces directly with Rexroth IndraDrive controllers and converts electrical power into mechanical torque for repeatable industrial motion. Its synchronous design supports accurate torque response during acceleration, steady running, and controlled stopping on automated equipment.
The motor uses a Motor Size 100 frame, and the internal stack corresponds to Motor Length D, giving a stator volume suited to mid-range torque output without a larger mounting footprint. Heat is dissipated through natural convection, so the housing must have enough surrounding space for unobstructed airflow. The electromagnetic system uses Winding Code 0300, which matches the electrical characteristics expected by compatible IndraDrive controllers. A plain shaft exits the front flange for direct coupling to gearboxes or belt pulleys, and the absence of a keyway helps avoid play that can appear in keyed connections. This shaft style is well suited to clamping couplings used on axes that need smooth torque transmission and accurate positioning.
The integrated optical encoder communicates through Hiperface and provides 128 signal periods per revolution, while its multiturn absolute function retains position information across power cycles. This allows the drive to recover axis position at startup without requiring a new reference move in many applications. Motion can be held during idle states by an electrically released brake rated at 70 Nm, which helps keep vertical or suspended loads from drifting when power is removed. Power enters through the A-side connector, allowing cable routing that stays organized around the motor housing. The combination of integrated feedback and an internal holding brake reduces the need for added external components on the machine axis.
Frequently Asked Questions about MSK100D-0300-NN-M1-AG2-NNNN:
Q: How is the MSK100D-0300-NN-M1-AG2-NNNN motor cooled?
A: This motor features natural convection cooling and operates without external fans.
Q: What encoder interface does the MSK100D-0300-NN-M1-AG2-NNNN use?
A: The encoder interface used is Hiperface, allowing reliable position feedback.
Q: What are the features of the holding brake on the MSK100D-0300-NN-M1-AG2-NNNN motor?
A: It is equipped with an electrically-released holding brake that provides 70 Nm of holding torque.
Q: What type of shaft does the MSK100D-0300-NN-M1-AG2-NNNN motor have?
A: The MSK100D-0300-NN-M1-AG2-NNNN motor has a plain shaft configuration.
Q: What type of encoder and resolution does the MSK100D-0300-NN-M1-AG2-NNNN have?
A: This model is built with an optical multiturn absolute encoder offering 128 signal periods of resolution.
