Product Description:

The MSK100C-0200-NN-M1-AG0-NNNN is a synchronous servo motor built by Bosch Rexroth Indramat for the MSK IndraDyn S Synchronous Motors series. In automated machinery, it supplies controlled torque and speed so axis controllers can handle interpolation, positioning, and tension control with repeatable motion. The motor combines a digital feedback system with a stator-mounted winding assembly to convert electrical drive commands into accurate mechanical output. This makes it suitable for conveyor gantries, processing spindles, and pick-and-place arms that require steady response during changing load conditions.

Heat is removed by natural convection, so the housing relies on ambient airflow instead of a powered fan. The feedback channel uses Hiperface communication, allowing the drive to exchange position, parameter, and diagnostic data over a two-wire connection. Inside the feedback module, an optical scale with 128 signal periods is read by photodiodes to provide fine incremental position data. Because the sensing method is optical, switching noise from the inverter is less likely to affect signal quality. The encoder also stores shaft position with a multi-turn absolute system, so the drive can retain turn information after power is removed.

The motor uses length C geometry and a size 100 frame, giving it a mounting face suited to standardized IEC dimensions for medium-torque applications. Power and brake leads exit on the A-side, which can simplify cable routing when the control cabinet is placed to the left of the axis. The stator uses winding code 0200, which indicates electrical values intended for compatible IndraDrive controllers in this torque class. A plain shaft supports direct coupling to precision gearboxes, and the motor comes without a holding brake, so holding force must be supplied by drive torque or an external clamp when power is removed.
