MSK100B-0200-NN-M1-BG0-NNNN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911311253
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
3 Minutes
16 Seconds
The Bosch Rexroth Indramat MSK100B-0200-NN-M1-BG0-NNNN is part of the MSK IndraDyn S Synchronous Motors series and features a standard design with natural convection cooling. This IndraDyn S synchronous servomotor has a plain shaft, motor length B, and a multiturn absolute optical encoder with Hiperface interface and 128 signal periods. The power connector is located on the B-side, and the motor does not include a holding brake.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK100B-0200-NN-M1-BG0-NNNN belongs to the MSK IndraDyn S Synchronous Motors series produced by Bosch Rexroth Indramat. It is an IndraDyn S synchronous servo motor intended for precise speed and position control in automated machinery. Closed-loop feedback from the integrated encoder lets the drive controller correct motion in real time, which supports accurate movement in packaging equipment, transfer systems, and other coordinated servo applications.
Heat is removed through natural convection, so the housing dissipates thermal energy without auxiliary fans or liquid circuits. Position data are transmitted over the Hiperface digital interface, giving the drive both absolute and incremental feedback channels on a single cable. This arrangement reduces cabling complexity while still giving the controller detailed rotor information throughout operation. The optical scanning head resolves the code disk into 128 signal periods, and the photodiode array uses an optical sensing method that eliminates magnetic drift. The encoder has multiturn absolute capability, so it records revolutions even while power is off and the axis can be referenced after power-up without external homing routines.
The motor is specified without a holding brake, meaning any static load must be secured by the drive or a mechanical lock when power is removed. A plain shaft is provided for direct coupling, which reduces torsional compliance compared with keyed interfaces and suits clamp-style couplings. Power wiring connects on side B of the stator, which can simplify cable routing when power and feedback leads need to be separated. With a frame size of 100, the unit fits machines sized for the larger MSK envelope, while it's B-length stack supports the continuous torque range expected from the standard design.
Frequently Asked Questions about MSK100B-0200-NN-M1-BG0-NNNN:
Q: What type of cooling is utilized in the MSK100B-0200-NN-M1-BG0-NNNN motor?
A: This model uses natural convection for cooling without the need for forced air systems.
Q: What kind of encoder does the MSK100B-0200-NN-M1-BG0-NNNN motor have?
A: The MSK100B-0200-NN-M1-BG0-NNNN is equipped with a multiturn absolute optical encoder using the Hiperface interface.
Q: Does the MSK100B-0200-NN-M1-BG0-NNNN motor have a holding brake?
A: There is no holding brake included with this motor.
Q: Where is the power connector located on the MSK100B-0200-NN-M1-BG0-NNNN?
A: The power connector on the MSK100B-0200-NN-M1-BG0-NNNN is positioned on the B-side of the motor.
Q: What type of shaft does the MSK100B-0200-NN-M1-BG0-NNNN motor feature?
A: This motor is manufactured with a plain shaft configuration.
