The Bosch Rexroth Indramat MSK076C-0450-NN-M3-UG1-NNNN is part of the MSK IndraDyn S Synchronous Motors series and features a plain shaft and a motor size of 076. This standard design servomotor uses natural convection cooling and operates within an ambient temperature range of 0 to 40°C. It has an electrically-released holding brake with a torque of 11 Nm and is rated IP65 for protection.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK076C-0450-NN-M3-UG1-NNNN is an IndraDyn S synchronous servomotor produced by Bosch Rexroth Indramat for the MSK IndraDyn S Synchronous Motors series. As a precision actuator, it converts drive current into controlled torque and speed for positioning axes, pick-and-place gantries, and coordinated conveyor sections in industrial automation. The unit is supplied in a standard design and operates without forced ventilation, which helps it fit compact machine layouts and moving assemblies where extra cooling hardware would add bulk. That arrangement suits transfer systems, indexing modules, and other equipment that depend on repeatable motion in limited installation space.
Heat is removed by natural convection, eliminating the need for external blowers. The housing has an IP65 enclosure rating, which keeps out dust and resists low-pressure water jets near the machine. Rotor position feedback is transmitted through the Hiperface interface for compatibility with Bosch Rexroth and third-party drives that support this protocol. An electrically released holding brake provides 11 Nm of static torque to hold the axis when power is removed. The motor uses winding code 0450, which corresponds to the electrical values expected by matching drive parameters. Mechanical output is transferred through a plain shaft, which suits couplings, pulleys, and other external transmission elements.
The motor uses frame size 076 with length C, giving it a mid-size mechanical envelope for general servo axes and helping it fit installations where torque capacity and mounting space must be balanced. The encoder is a multi-turn absolute device with capacitive technology, 16 signal periods, and a connector that can be rotated 240°, so cable routing can be adapted to the available machine space. Because the feedback is absolute, the control system can identify shaft position at startup without a reference move in many axis designs. Insulation class 155 supports the winding temperatures associated with cyclic operation in ambient conditions from 0 to 40 °C. The rotatable connector also helps when cable exits must avoid guards, slides, or adjacent machine structures.
Frequently Asked Questions about MSK076C-0450-NN-M3-UG1-NNNN:
Q: What type of shaft does the MSK076C-0450-NN-M3-UG1-NNNN motor have?
A: This model is equipped with a plain shaft for straightforward coupling to machinery.
Q: Does the MSK076C-0450-NN-M3-UG1-NNNN have a holding brake and what is its torque?
A: The MSK076C-0450-NN-M3-UG1-NNNN comes with an electrically-released holding brake providing 11 Nm of torque.
Q: What encoder interface and resolution are featured on the MSK076C-0450-NN-M3-UG1-NNNN?
A: This motor utilizes a Hiperface-compatible multiturn absolute capacitive encoder offering 16 signal periods of resolution.
Q: How is the MSK076C-0450-NN-M3-UG1-NNNN motor cooled?
A: The cooling for this model is achieved via natural convection, without external fans or forced air.
Q: What level of protection does the MSK076C-0450-NN-M3-UG1-NNNN offer?
A: The MSK076C-0450-NN-M3-UG1-NNNN has an IP65 protection rating, ensuring it is dust tight and protected against water jets.
