The Bosch Rexroth Indramat MSK076C-0300-NN-M3-UG0-NNNN is an IndraDyn S Synchronous Servomotor from the MSK IndraDyn S Synchronous Motors series. It features natural convection cooling, a rotatable encoder connector, and an IP65 protection rating. The servomotor uses Hiperface interface with capacitive multiturn absolute encoder technology, and operates in temperatures from 0 to 40 degrees Celsius.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK076C-0300-NN-M3-UG0-NNNN is a synchronous servomotor built by Bosch Rexroth Indramat and assigned to the MSK IndraDyn S Synchronous Motors series. It supplies tightly regulated mechanical power for indexing tables, gantry axes, and other motion sequences in automated production lines, where coordinated velocity and position are commanded from an electronic drive and converted into repeatable rotary motion at the shaft. Its compact frame permits direct mounting to gearheads or load shafts without intermediary belt transmissions. This arrangement suits machinery that needs precise acceleration, stable speed control, and a short drivetrain.
Within that frame, the motor uses size code 076 and length code C, so the housing diameter and stack depth fit a mid-range mechanical envelope. It is built in the standard design variant used across the series, so the external motor form follows the usual configuration for this frame. Winding code 0300 identifies the electrical winding arrangement used by the drive during current control. Cooling relies on natural convection, so heat dissipates through the ribbed stator surface without fans or liquid jackets. The housing is rated IP65, which helps block dust and low-pressure water during machine operation. The motor has a plain shaft and comes without a holding brake, and a rotatable 240° connector lets the capacitive encoder cable be positioned to suit nearby hardware.
The feedback link uses the Hiperface protocol in multiturn absolute form, allowing the controller to retain shaft position information across multiple revolutions after a power cycle. This feedback channel supports closed-loop speed and position regulation during normal operation. Thermal capability is supported by insulation class 155, which allows the winding system to operate at elevated internal temperatures. The motor is intended for ambient temperatures of 0–40 °C, a range that covers typical indoor industrial conditions. The capacitive encoder provides 16 signal periods per revolution, giving the drive the base feedback needed for stable motion control.
Frequently Asked Questions about MSK076C-0300-NN-M3-UG0-NNNN:
Q: How is the MSK076C-0300-NN-M3-UG0-NNNN motor cooled?
A: This model uses natural convection for cooling and does not require external fans.
Q: What is the capability of the encoder connector on the MSK076C-0300-NN-M3-UG0-NNNN?
A: The encoder connector is rotatable up to 240°, offering flexible installation options.
Q: What level of environmental protection does the MSK076C-0300-NN-M3-UG0-NNNN provide?
A: Its protection rating is IP65, giving it dust tightness and protection against low-pressure jets of water.
Q: What type of encoder is used in the MSK076C-0300-NN-M3-UG0-NNNN motor?
A: This motor features a multiturn absolute encoder with Hiperface interface for precise positional feedback.
Q: What is the shaft type of the MSK076C-0300-NN-M3-UG0-NNNN?
A: The MSK076C-0300-NN-M3-UG0-NNNN has a plain shaft design without keyway or additional mechanical features.
