MSK076C-0300-NN-M1-UG0-NSNN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911331916
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
4 Minutes
0 Seconds
The Bosch Rexroth Indramat MSK076C-0300-NN-M1-UG0-NSNN is part of the MSK IndraDyn S Synchronous Motors series. This servomotor uses natural convection cooling, features a rotatable 240 degree encoder connector, and supports Hiperface multiturn absolute encoders with optical technology. It has IP65 protection rating, standard and explosion protection design, and operates within a 0 to 40 degrees Celsius ambient temperature range.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK076C-0300-NN-M1-UG0-NSNN servo motor is produced by Bosch Rexroth Indramat for the MSK IndraDyn S Synchronous Motors series. With frame size 076 and length C, the unit fits medium-torque applications that require precise rotary motion. In industrial automation, it pairs with IndraDrive power stages to position tooling, index workpieces, or synchronize conveyor lanes through closed-loop motion control. Its 0300 winding balances current demand with torque density, which supports responsive acceleration and stable operation on repeat-cycle axes.
Cooling is handled by natural convection, so heat leaves the stator through the housing surface without fans or liquid lines. The motor is approved for standard installations and for areas that require explosion protection. Position feedback is provided through a Hiperface optical encoder that offers 128 signal periods per revolution, giving the drive the data it needs for commutation and motion control. Because the shaft is a plain shaft, the mechanical interface relies on external clamps or couplings rather than a keyway. A sealing system rated at IP65 blocks airborne particles and water jets from reaching internal laminations, and the motor is supplied without a holding brake, so loads must be secured externally when power is removed.
During installation, the encoder plug can be oriented with a rotatable through 240° connector, which helps route cables in compact machines. The encoder stores position data on a multiturn absolute scale, allowing the controller to recover angle information immediately after power cycles. Class 155 insulation allows the copper windings to withstand temperatures that match the passive cooling arrangement. Continuous service is specified for ambient air from 0 to 40 °C, which covers most assembly areas and keeps thermal rise within the motor's permissible limit.
Frequently Asked Questions about MSK076C-0300-NN-M1-UG0-NSNN:
Q: What type of cooling does the MSK076C-0300-NN-M1-UG0-NSNN servomotor use?
A: The MSK076C-0300-NN-M1-UG0-NSNN servomotor uses natural convection for cooling, which means it operates without external fans or forced air.
Q: What type of encoder and interface are featured on the MSK076C-0300-NN-M1-UG0-NSNN motor?
A: This servomotor utilizes a multiturn absolute optical encoder with Hiperface interface and an encoder resolution of 128 signal periods.
Q: What is the operating ambient temperature range for the MSK076C-0300-NN-M1-UG0-NSNN?
A: The model operates reliably within an ambient temperature range of 0 to 40°C.
Q: Is a holding brake included with the MSK076C-0300-NN-M1-UG0-NSNN motor?
A: This motor does not come equipped with a holding brake.
Q: What is the protection rating of the MSK076C-0300-NN-M1-UG0-NSNN servomotor?
A: The MSK076C-0300-NN-M1-UG0-NSNN has an IP65 protection rating, which ensures dust tightness and protection against low-pressure water jets.
