MSK075E-0200-NN-S2-UG2-RNNN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911322045
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
6 Minutes
34 Seconds
The Bosch Rexroth Indramat MSK075E-0200-NN-S2-UG2-RNNN is an IndraDyn S Synchronous Servomotor in the MSK IndraDyn S Synchronous Motors series. It features a plain shaft, increased concentricity design, and uses natural convection for cooling. This motor includes an electrically-released holding brake with a torque of 30 Nm and a rotatable 240° encoder connector with EnDat2.1 interface and optical singleturn technology.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK075E-0200-NN-S2-UG2-RNNN is a synchronous servo motor built by Bosch Rexroth Indramat for the MSK IndraDyn S Synchronous Motors series. It belongs to the IndraDyn S synchronous servo motor product type and converts electrical energy into controlled rotary motion for closed-loop axes on packaging machines, handling gantries, and general automation cells. Its electromagnetic design and encoder system support accurate position feedback, while its compact mechanical layout fits drive trains that require high dynamic response in space-limited installations used in automotive and food processing equipment. This makes it suitable for synchronized motion tasks that depend on repeatable speed and position control.
Winding code 0200 indicates the copper fill and impedance selected for moderate current at standard drive voltages. Cooling is done by natural convection, so the motor disperses heat through its housing without auxiliary fans. Increased concentricity helps reduce radial runout and limits vibration during rapid acceleration. The encoder connector can be rotated through 240°, which allows multiple cable exit directions where routing space is restricted. The feedback channel uses the EnDat2.1 interface, and the optical scale provides 2048 signal periods per revolution. Combined with the optical sensor element and single-turn tracking, this arrangement gives fine angular resolution to the drive controller. The interface supports precise digital position transfer to the connected controller.
An electrically released holding brake delivers 30 Nm of static torque to lock the axis when the controller is disabled. This brake supports passive holding when the axis must remain in position at standstill. The output end uses a plain shaft, allowing direct clamp couplings without keyway-induced play. Frame size 075 sets the flange pattern used for mechanical mounting. Length code E indicates a longer active stack, which increases continuous torque compared with shorter motor lengths. This combination suits applications that need secure load holding, direct shaft coupling, and stable torque from a compact servo motor.
Frequently Asked Questions about MSK075E-0200-NN-S2-UG2-RNNN:
Q: What shaft type does the MSK075E-0200-NN-S2-UG2-RNN motor use?
A: The MSK075E-0200-NN-S2-UG2-RNN features a plain shaft configuration.
Q: What type of encoder is included with the MSK075E-0200-NN-S2-UG2-RNN motor?
A: This model is equipped with a singleturn optical encoder using EnDat2.1 interface and provides 2048 signal periods resolution.
Q: How is the MSK075E-0200-NN-S2-UG2-RNN motor cooled?
A: The MSK075E-0200-NN-S2-UG2-RNN utilizes natural convection for cooling.
Q: What type and strength of holding brake does the MSK075E-0200-NN-S2-UG2-RNN have?
A: This motor includes an electrically-released holding brake with a torque rating of 30 Nm.
Q: What special design feature distinguishes the MSK075E-0200-NN-S2-UG2-RNN?
A: The MSK075E-0200-NN-S2-UG2-RNN is designed with increased concentricity for improved rotational precision.
