Product Description:

The MSK071C-0300-NN-M1-AP0-NNAN is an IndraDyn S synchronous servomotor in the MSK IndraDyn S Synchronous Motors series. It is intended for closed-loop servo axes that need rapid acceleration and consistent torque in pick-and-place, packaging, and metal-cutting equipment. The compact frame integrates feedback, winding, and power terminals so a compatible drive controller can deliver highly repeatable rotary motion without external gearing. It is suited to applications that require repeatable starts, stops, and speed changes across short machine cycles. This integrated layout helps reduce external hardware and supports compact axis arrangements in automated machinery.

Heat is removed through natural convection, so no external blower or liquid circuit is required when the installation allows free airflow around the housing. Position data are exchanged through the Hiperface interface, and the optical encoder provides 128 signal periods for smooth incremental feedback to the drive. The motor has an enclosure rating of IP65, which helps keep dust and water jets away from internal components during machine operation. The allowable ambient temperature ranges from 0 to 40 °C, and the reduced runout shaft design supports accurate rotation during high-speed sequences.

The feedback module retains position data with a multiturn absolute measuring system, so homing is not required after each power cycle. Mechanical output is delivered through a shaft with keyway, which allows positive torque transfer to couplings and driven elements. Insulation class 155 supports the winding under elevated thermal load, and winding code 0300 matches the electrical characteristics expected by compatible MSK drives. The motor is built in size 071 with length C, the power plug is located on the A-side, and the unit is supplied without a holding brake, so static load retention must be provided externally when needed.
