MSK070D-0300-NN-M1-UP1-NSNN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911331103
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
3 Minutes
7 Seconds
The Bosch Rexroth Indramat MSK070D-0300-NN-M1-UP1-NSNN is part of the MSK IndraDyn S Synchronous Motors series, featuring natural convection cooling and an IP65 protection rating. This servomotor comes with a multiturn absolute optical encoder supporting Hiperface interface and a holding brake with 23 Nm torque. It is equipped with a shaft and keyway and is designed for environments with ambient temperatures from 0 to 40 degrees Celsius.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK070D-0300-NN-M1-UP1-NSNN belongs to the MSK IndraDyn S Synchronous Motors series produced by Bosch Rexroth Indramat. It is an IndraDyn S synchronous servomotor intended for industrial automation cells that require controlled rotary motion. The motor converts electrical energy into precise movement for positioning, indexing, and continuous-duty axes. Typical uses include transfer systems, coordinated machine axes, and other applications that depend on repeatable speed and position control.
Heat is removed through natural convection, so no external fan or liquid circuit is required. This cooling method keeps the installation simpler because the motor does not depend on added airflow hardware. The housing has an IP65 protection rating that seals out dust and resists water jets during machine operation. A shaft with keyway provides positive mechanical coupling, and an electrically released holding brake supplies 23 Nm of static torque to secure vertical or load-bearing axes at standstill. The unit is certified for both standard and explosion-protected zones. Feedback wiring is supported by a connector that is rotatable through 240°, and position data is transmitted over a Hiperface interface for compatible drive systems.
The position sensor uses optical scanning and provides 128 signal periods per revolution. Its multi-turn absolute design retains turn information during power loss, which removes the need for a homing cycle after restart. Continuous operation is permitted in ambient temperatures from 0 to 40 °C, which fits typical enclosed machine environments. Thermal insulation class 155 supports winding temperatures up to 155 °C within the insulation system rating. Frame code 070 with length D sets the stator size and stack height, and winding code 0300 matches the electrical values required by IndraDrive power sections.
Frequently Asked Questions about MSK070D-0300-NN-M1-UP1-NSNN:
Q: What type of encoder connector does the MSK070D-0300-NN-M1-UP1-NSNN motor use?
A: The MSK070D-0300-NN-M1-UP1-NSNN features a rotatable encoder connector with 240° flexibility for cable management.
Q: Which encoder interface is provided on the MSK070D-0300-NN-M1-UP1-NSNN?
A: Hiperface is the encoder interface standard included with this model.
Q: What are the specifications of the holding brake on this model?
A: The included holding brake is electrically released and delivers 23 Nm of torque.
Q: What is the permissible operating temperature range for the MSK070D-0300-NN-M1-UP1-NSNN?
A: This motor operates within an ambient temperature range from 0°C to 40°C.
Q: What is the protection rating of the MSK070D-0300-NN-M1-UP1-NSNN motor?
A: The MSK070D-0300-NN-M1-UP1-NSNN features an IP65 protection rating, offering resistance to dust and water jets.
