MSK070C-0450-NN-M1-UP0-NNNN

  • Rated 4.4 (35 total ratings)
  • MPN: R911299756
  • Stock: In-Stock, Ships 1-2 Days
  • Factory New Pricing Available!
    Request a Quote!
  • Call for Expedited Shipping and Product Condition Options
The MSK070C-0450-NN-M1-UP0-NNNN is manufactured by Rexroth Indramat Bosch as part of the MSK Servo Motor Series. It features a continuous torque of 14.5 Nm and a continuous current of 9.2 A. It also displays a maximum torque of 33.0 Nmand a maximum current of 36.9 A and a winding inductive of 4,000 mH

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock!

MSK070C-0450-NN-M1-UP0-NNNN

  • Rated 4.4 (35 total ratings)
  • MPN: R911299756
  • Stock: In-Stock, Ships 1-2 Days
  • Factory New Pricing Available!
    Request a Quote!
  • Call for Expedited Shipping and Product Condition Options
The MSK070C-0450-NN-M1-UP0-NNNN is manufactured by Rexroth Indramat Bosch as part of the MSK Servo Motor Series. It features a continuous torque of 14.5 Nm and a continuous current of 9.2 A. It also displays a maximum torque of 33.0 Nmand a maximum current of 36.9 A and a winding inductive of 4,000 mH

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a MSK070C-0450-NN-M1-UP0-NNNN to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The MSK synchronous motors constructed by the Rexroth Bosch group can be used together with IndraDrive and Indramat drives. These motors offer high torque density. The MSK motors are the typical choices for printing presses, food preparation as well as packaging machines, and metal-forming applications. Besides high-power density, these motors have the ability to offer high precision. These motors use optical encoder systems. The MSK synchronous motors have adopted a modular design. This design makes it possible for the users to pull them off the machines and replace them whenever necessary. For optimal as well as safe operation of these motors, correct and appropriate storage, transport, mounting, installation, maintenance, and operational care are necessary. Operation of the MSK motors can only take place when all the regulations and requirements of national EMC are met. During the operation of these motors, the users should observe the ambient as well as operating conditions specified by the manufacturer. Only Rexroth approved accessories as well as spare parts should be used in the MSK motors.

The MSK070C-0450-NN-M1-UP0-NNNN motor is equipped with a multiturn absolute optical encoder. This motor has a hiperface interface having 128 signal periods. The output shaft of this motor has a keyway, and it has been sealed with a ring. The keyway allows for the transmission of form-fitting torques that bears constant direction and low requirements for the connection of the shaft-hub. This motor is balanced with a complete key. Therefore, the machine to be run or driven should be balanced without the use of a key. The MSK070C-0450-NN-M1-UP0-NNNN motor is available without a holding brake. The gearbox of this motor can be optimally adjusted. The housing and output shaft of this motor are standardly designed and have IP 65 protection degree.

  • MSK-070C-0450-NN-M1-UP0-NNNN
  • MSK070C 0450 NN M1 UP0 NNNN
  • MSK070C0450NNM1UP0NNNN
  • MSK70C-0450-NN-M1-UP0-NNNN

MSK070C-0450-NN-M1-UP0-NNNN Technical Specifications

Continuous Current at Standstill 100 K: 9.2 A
Operating Temperature Range: 0 to +40 degree centigrade
Electrical Connection: 240 degree rotatable plug
Maximum Torque: 33 Nm
Maximum Current: 36.9 A
Max. Speed: 6000 rpm
Shaft: Shaft with Keyways
Torque Constant at 20 °C: 1.16 Nm/A
Voltage Constant at 20 °C: 71.3 V/min-1
Moment of Inertia: 0.00291 kgm2

Frequently Asked Questions about MSK070C-0450-NN-M1-UP0-NNNN


Q: What type of encoder does the MSK070C-0450-NN-M1-UP0-NNNN motor utilize?

A: The MSK070C-0450-NN-M1-UP0-NNNN motor employs a multiturn absolute optical encoder. This encoder system provides precision positioning and feedback without requiring re-homing after a power cycle.

Q: How does the hiperface interface of the MSK070C-0450-NN-M1-UP0-NNNN motor function in terms of signal periods?

A: The hiperface interface of the motor features 128 signal periods, ensuring high-resolution feedback and seamless integration with advanced drive systems.

Q: What is the purpose of the keyway on the output shaft of the motor?

A: The keyway on the motor's output shaft facilitates the transmission of form-fitting torques, bearing a constant direction and ensuring low connection requirements for the shaft-hub.

Q: How does the MSK070C-0450-NN-M1-UP0-NNNN motor's housing unit protect its internal components?

A: The motor's housing adheres to IP65 protection standards, shielding internal components from both solid and liquid interference.

Q: How does the MSK070C-0450-NN-M1-UP0-NNNN manage the heat it produces during operation?

A: Heat regulation is achieved through natural convection, though an external air blower can be attached for enhanced temperature management.

Internal Product Review

  • ‘‘The MSK070C-0450-NN-M1-UP0-NNNN exhibits exceptional quality with its IP65 protective housing and efficient heat management through natural convection. Notably silent at <75 decibels.’’
