MSK070C-0300-NN-M1-UP1-NNNN

  • Rated 4.5 (28 total ratings)
  • MPN: R911315586
  • Stock: In-Stock, Ships Fast
  • Factory New Pricing Available!
    Request a Quote!
  • Call for Expedited Shipping and Product Condition Options
The MSK070C-0300-NN-M1-UP1-NNNN is manufactured by Rexroth Indramat Bosch as part of the MSK Servo Motor Series. It features a continuous torque of 14.5 Nm and a continuous current of 9.2 A. It also displays a maximum torque of 33.0 Nmand a maximum current of 32.8 A and a winding inductive of 8,300 mH

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock!

MSK070C-0300-NN-M1-UP1-NNNN

  • Rated 4.5 (28 total ratings)
  • MPN: R911315586
  • Stock: In-Stock, Ships Fast
  • Factory New Pricing Available!
    Request a Quote!
  • Call for Expedited Shipping and Product Condition Options
The MSK070C-0300-NN-M1-UP1-NNNN is manufactured by Rexroth Indramat Bosch as part of the MSK Servo Motor Series. It features a continuous torque of 14.5 Nm and a continuous current of 9.2 A. It also displays a maximum torque of 33.0 Nmand a maximum current of 32.8 A and a winding inductive of 8,300 mH

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a MSK070C-0300-NN-M1-UP1-NNNN to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The MSK070C-0300-NN-M1-UP1-NNNN is a synchronous motor manufactured by Bosch Rexroth a world-renowned manufacturer of electrical parts. This motor is from the IndraDyn S line up and the MSK series. This synchronous motor has the ability to provide up to 12 Nm continuous torque at standstill and can provide a maximum torque of 43.5 Nm. The motor has a length of C and features 0300 windings. There is a connector that is rotatable up to 240 degrees and the motor utilizes a natural convection cooling type. The shaft type on this MSK motor is a shaft with keyway per DIN 6885-1 with a shaft sealing ring.

One of the features that sets this motor apart from motors in other ranges is its ability to provide a wide spectrum of power while having narrow size increments. The unit has a very high torque density allowing for maximum torques of as much as 495 Nm. The maximum speed of the motor is 9000 rpm and features IP65 protection.

The MSK070C-0300-NN-M1-UP1-NNNN is made by Bosch Rexroth and has been built to all the top quality specifications we expect from the brand. They have been in the business of electrical parts manufacturing for decades. During this time they have continued to maintain their name as a producer of quality items and a provider of quality customer service even post-purchase. As such you can be certain when you purchase and use one of the MSK synchronous motors such as this one, you are making a top-quality purchase. This and any other purchase from this manufacturer will provide value for money and will boost the productivity of your operating line.

  • MSK-070C-0300-NN-M1-UP1-NNNN
  • MSK070C 0300 NN M1 UP1 NNNN
  • MSK070C0300NNM1UP1NNNN
  • MSK70C-0300-NN-M1-UP1-NNNN

MSK070C-0300-NN-M1-UP1-NNNN Technical Specifications

Continuous Current at Standstill 100 K: 9.2 A
Maximum Speed: 5,500 min-1
Cooling : Natural Convection
Encoder: Optical Multiturn Absolute Encoder with 2048 Increaments
Shaft: Shaft With keyway and sealing ring
Holding Brake: Present
Holding torque: 23 Nm
Maximum Current: 32.8A
Maximum Torque: 33Nm
Number of Pole Pairs: 6

Frequently Asked Questions about MSK070C-0300-NN-M1-UP1-NNNN


Q: How does the holding brake in the MSK070C-0300-NN-M1-UP1-NNNN operate?

A: The holding brake in the MSK070C-0300-NN-M1-UP1-NNNN works according to the "Electrically Releasing" principle. The brake opens when operating voltage is applied and closes when the motor is at a standstill.

Q: What are the electrical connectors important for the operation of the MSK070C-0300-NN-M1-UP1-NNNN?

A: The MSK070C-0300-NN-M1-UP1-NNNN requires the power connector (Including connector for temparature sensor and holding brake) and the motor feedback connector. Both connectors are designed as plug-in connectors.

Q: Can the MSK070C-0300-NN-M1-UP1-NNNN be operated without fan units?

A: Yes, the use of additional fan units is only recommended when the motor is required to handled high loads.

Q: How does the MSK070C-0300-NN-M1-UP1-NNNN monitor its operational temperature to prevent overheating?

A: The temperature of the MSK070C-0300-NN-M1-UP1-NNNN is monitored by an internal temperature sensor and internal temperature model. These two systems operate independently of each other.

Q: How is the MSK070C-0300-NN-M1-UP1-NNNN delivered.

A: The MSK070C-0300-NN-M1-UP1-NNNN is delivered in cardboard boxes or crates. Packing units on pallets are secured by means of retaining straps.

Internal Product Review

  • ‘‘The MSK070C-0300-NN-M1-UP1-NNNN is powerful and easy to use. Its flexibility also makes it cost effective. ’’
