The Bosch Rexroth Indramat MSK061C-0600-NN-S1-UP0-NSNN is an IndraDyn S Synchronous Servomotor with a shaft with keyway and a motor size of 061 and length C. Part of the MSK IndraDyn S Synchronous Motors series, it features optical Hiperface encoder technology with a rotatable 240 degree connector and singleturn encoder. The motor provides IP65 protection rating, natural convection cooling, and is designed for standard and explosion protection.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK061C-0600-NN-S1-UP0-NSNN servo motor is manufactured by Bosch Rexroth Indramat as part of the MSK IndraDyn S Synchronous Motors series. It serves as a torque source for CNC tables, pick-and-place actuators, and other closed-loop axes where compact, high-accuracy drive stages are needed. The unit uses motor size 061 and length code C, giving it a mid-frame format that suits compact machine sections without requiring a larger motor envelope. Its standard design and explosion-protection option allow the same basic motor platform to be used in ordinary production areas or in hazardous zones where ignition control is required.
Heat generated during operation is removed by natural convection, so no external blower or liquid circuit is required. The stator uses winding code 0600, which is matched to compatible drive amplifiers in the series. Position feedback is routed through a 240° rotatable connector from a Hiperface sensor that provides 128 signal periods per revolution, uses optical scanning, and operates as a single-turn device for absolute position within one mechanical revolution. The rotatable connector helps route the feedback cable more cleanly in compact cabinets, and thermal class 155 supports winding insulation at elevated operating temperatures.
The output end uses a shaft with a keyway, which allows positive torque transfer to pulleys, couplings, or similar driven elements. The motor is supplied without a holding brake, so any load that must remain fixed during power loss requires external holding force. The housing has an IP65 enclosure rating that helps keep dust and low-pressure water jets away from internal components, making the motor suitable for exposed machine locations. Continuous operation is permitted in ambient temperatures from 0–40 °C, and the installation should leave enough open space around the housing for heat to leave the surface without obstruction.
Frequently Asked Questions about MSK061C-0600-NN-S1-UP0-NSNN:
Q: What type of cooling method is used in the MSK061C-0600-NN-S1-UP0-NSNN motor?
A: This model features natural convection cooling and does not require additional external cooling equipment.
Q: What type of encoder is included with the MSK061C-0600-NN-S1-UP0-NSNN and what is its resolution?
A: The MSK061C-0600-NN-S1-UP0-NSNN is equipped with a singleturn optical encoder using Hiperface interface with a resolution of 128 signal periods.
Q: What kind of shaft type does the MSK061C-0600-NN-S1-UP0-NSNN have?
A: The shaft on this motor includes a keyway, allowing for secure attachment to compatible mechanical components.
Q: Is a holding brake included in the MSK061C-0600-NN-S1-UP0-NSNN motor?
A: This motor is manufactured without a holding brake.
Q: What is the acceptable operating temperature range for the MSK061C-0600-NN-S1-UP0-NSNN?
A: The MSK061C-0600-NN-S1-UP0-NSNN operates in ambient temperatures ranging from 0 to 40°C.
