Product Description:

The MSK061C-0600-NN-S1-UG1-NNNN is an IndraDyn S synchronous servo motor manufactured by Bosch Rexroth Indramat for the MSK IndraDyn S Synchronous Motors series. The motor supplies regulated torque and speed to compact axes used in packaging machines, material-handling gantries, and machining centers. By combining a high-energy permanent-magnet rotor with precise optical feedback, it supports closed-loop operation on IndraDrive amplifiers and helps maintain consistent process quality in industrial automation.

This model relies on natural convection to remove heat from the stator, so it can be installed in cabinets that lack forced ventilation. The electrically released brake generates 10 Nm of holding torque, allowing vertical or suspended loads to remain fixed when power is off. A plain shaft provides a smooth coupling surface for shrink discs or clamp hubs without keyways. Frame size 061 uses the flange geometry assigned to that motor size, while length class C indicates the active stack depth used for continuous power output. With its standard housing design, the motor keeps a compact envelope for multi-axis assemblies and supports direct gearbox mounting.

Position information is transferred through the Hiperface serial interface generated by an optical scanning system. The encoder tracks rotor angle within a single-turn range and delivers 128 signal periods per mechanical revolution, which the drive interpolates for fine position feedback. A rotatable 240° M23 connector allows the feedback cable to be routed toward the nearest wiring path, which helps reduce bend stress. Internally, winding code 0600 sets the copper fill, resistance, and inductance so current delivery remains consistent with the motor's thermal capacity. The overall arrangement supports deterministic motion without additional cooling hardware.
