Product Description:

The MSK061C-0600-NN-M1-UP1-NNNN is a synchronous servo motor produced by Bosch Rexroth Indramat within the MSK IndraDyn S Synchronous Motors series. As an IndraDyn S servo motor, it converts drive-controller current into controlled mechanical torque for axes that require accurate position and velocity control in automated machinery, conveyors, and packaging equipment. It is used with IndraDrive servo amplifiers to create closed-loop motion stages that maintain repeatable performance over continuous duty cycles. This operating role makes it suitable for indexing axes, feeders, and handling units that depend on stable torque response during repeated starts and stops.

Cooling is done by natural convection, so heat exits through the housing and no external fan or liquid loop is needed. The frame size is 061, while length code C provides additional active material for higher torque without enlarging the mounting footprint. Internal copper uses winding code 0600, which is matched to IndraDrive current ratings. Feedback is handled by a Hiperface optical encoder that delivers 128 signal periods per revolution, allowing high-resolution position monitoring without separate resolver hardware. The encoder also supplies position data for commutation and motion feedback, which supports stable speed control across a wide operating range.

For holding functions, an electrically released brake supplies 10 Nm of static torque so vertical or suspended loads remain fixed when power is removed. The feedback device is a multi-turn absolute model, so the drive retains a precise shaft count even after power loss and startup does not require a repeated reference search. Cabling is simplified by an encoder plug that is rotatable through 240°, making right-angle or straight-out routing possible inside tight enclosures. The rotating connector also helps reduce cable strain when space around the motor is limited. A shaft with keyway transmits torque without relying on friction alone.
