MSK061C-0600-NN-M1-UG1-NNC1 Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911337758
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
3 Minutes
23 Seconds
The Bosch Rexroth Indramat MSK061C-0600-NN-M1-UG1-NNC1 is part of the MSK IndraDyn S Synchronous Motors series and features a plain shaft design with a C length and size 061. It has an optical multiturn absolute encoder with Hiperface interface and supports a rotatable 240 degree encoder connector. The servomotor uses natural convection cooling, provides an IP65 protection rating, and includes an electrically-released holding brake with 10 Nm holding torque.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK061C-0600-NN-M1-UG1-NNC1 is an IndraDyn S synchronous servomotor built by Bosch Rexroth Indramat and assigned to the MSK IndraDyn S Synchronous Motors series. Designed for closed-loop positioning and speed control on packaging lines, handling modules, and machine tools, this motor converts drive current into precise rotary motion without mechanical gearing. Its integrated feedback and sealed housing allow it to serve as a direct-coupled actuator inside automation cells where accuracy and long service life are required. The direct-coupled layout also helps reduce backlash from external transmission elements and supports fast response to changing motion commands.
Heat produced in the stator is removed through natural convection, so the motor can be mounted without a forced-air duct as long as free airflow surrounds its frame. Position feedback is carried through a rotatable 240° connector from the optical encoder, which helps simplify cable routing in tight machine spaces. The encoder uses the Hiperface protocol and generates 128 signal periods per revolution; together with its multiturn absolute design, the drive controller can recover the shaft angle and the total number of revolutions after power loss. For holding tasks, an electrically released brake delivers 10 Nm of static torque, keeping vertical or suspended loads immobile when the drive is disabled.
The housing meets IP65 ingress protection, blocking dust and low-pressure water jets so the unit can be installed on open machine frames. It operates reliably in ambient temperatures from 0–40 °C and uses thermal class 155 insulation, which allows the windings to withstand elevated internal temperatures during cyclic duty. A plain shaft simplifies coupling to gears or belt pulleys and avoids keyway stress concentrations. The motor has size 061 and length code C for its frame dimensions, while winding code 0600 identifies the stator turns and impedance used by the matching drive. This arrangement makes the motor suitable for applications that need a compact servo with direct coupling and consistent feedback retention after shutdown.
Frequently Asked Questions about MSK061C-0600-NN-M1-UG1-NNC1:
Q: What type of encoder does the MSK061C-0600-NN-M1-UG1-NNC1 motor use?
A: The MSK061C-0600-NN-M1-UG1-NNC1 motor is equipped with a multiturn absolute encoder using optical technology.
Q: Does the MSK061C-0600-NN-M1-UG1-NNC1 include a holding brake and what is its torque?
A: This model is supplied with a holding brake that is electrically released and delivers a torque of 10 Nm.
Q: What shaft type is offered on the MSK061C-0600-NN-M1-UG1-NNC1 motor?
A: The shaft on the MSK061C-0600-NN-M1-UG1-NNC1 is a plain shaft configuration.
Q: What is the protection rating of the MSK061C-0600-NN-M1-UG1-NNC1 motor?
A: This motor features a protection rating of IP65, providing solid protection against dust and water ingress.
Q: How is the MSK061C-0600-NN-M1-UG1-NNC1 motor cooled?
A: The cooling method for the MSK061C-0600-NN-M1-UG1-NNC1 is natural convection, so it operates without external fans.
