MSK061C-0300-NN-S2-UP0-RNNN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911327982
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
4 Minutes
32 Seconds
The Bosch Rexroth Indramat MSK061C-0300-NN-S2-UP0-RNNN is an IndraDyn S Synchronous Servomotor from the MSK IndraDyn S Synchronous Motors series. It features a shaft with keyway, natural convection cooling, and an IP65 protection rating. The motor includes an EnDat2.1 singleturn optical encoder with a 2048 signal period resolution and a rotatable 240-degree connector.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK061C-0300-NN-S2-UP0-RNNN is a synchronous servomotor produced by Bosch Rexroth Indramat within the MSK IndraDyn S Synchronous Motors series. It provides precise torque and speed control for automated axes, allowing numerical controllers to position loads with the accuracy required in packaging equipment, pick-and-place gantries, and metal-cutting spindles. Its size 061 housing with length C gives it a compact format for machine axes that need a balance of output and installation space. The motor also uses winding code 0300, an increased-concentricity design, and a shaft with a keyway to support accurate coupling alignment and secure torque transfer.
This model relies on natural convection to carry heat away from the stator, so no external fan or coolant circuit is required when the motor is installed in free air. That cooling method reduces the number of auxiliary components around the axis and keeps the layout simple. Position feedback is transmitted through the digital EnDat2.1 interface, giving the drive access to diagnostic data and automatic parameter transfer. The feedback element uses an optical measuring system with 2048 signal periods, which supports smooth commutation and stable low-speed motion. A housing and terminal design rated to IP65 helps keep dust and low-pressure water jets away from the windings in typical industrial environments.
Servo wiring exits through a rotatable 240° connector, so the cable direction can be adjusted after the motor is mounted. This makes it easier to route the cable in tight machine spaces or around nearby mechanical parts. The encoder is a single-turn variant that reports absolute shaft angle within one revolution, which suits short-stroke axes that reference before each cycle. The unit is supplied without a holding brake, so static load retention must be handled by the drive or by external clamps. Continuous service is permitted from 0 to 40 °C, and insulation class 155 supports the motor’s thermal capability in standard cabinet and machine environments.
Frequently Asked Questions about MSK061C-0300-NN-S2-UP0-RNNN:
Q: Does the MSK061C-0300-NN-S2-UP0-RNNN motor have a holding brake?
A: This model is manufactured without a holding brake.
Q: What type of shaft does the MSK061C-0300-NN-S2-UP0-RNNN motor use?
A: The shaft on the MSK061C-0300-NN-S2-UP0-RNNN features a keyway for secure coupling to mechanical loads.
Q: How is the MSK061C-0300-NN-S2-UP0-RNNN motor cooled?
A: The cooling method for this motor is natural convection, allowing it to operate without the need for external cooling devices.
Q: What kind of encoder technology and resolution does this motor feature?
A: The MSK061C-0300-NN-S2-UP0-RNNN uses an optical encoder with EnDat2.1 interface and 2048 signal periods resolution.
Q: What is the protection rating of the MSK061C-0300-NN-S2-UP0-RNNN motor?
A: The protection rating for this motor is IP65, ensuring resistance against dust and low-pressure water jets.
